Spcification:
Dead band: 1μs
Working frequence: 1520μs / 330hz
Motor: coreless motor
Operating Speed (6V): 0.12sec/60°
Operating Speed (7.4V): 0.09sec/60°
Stall Torque (6V): 27.1 kg.cm
Stall Torque (7.4V): 32.3kg.cm
Dimensions: 40.5X20.5X36mm /1.59X0.80X1.42in
Weight: 73g(2.57oz)
Connector Wire Length: JR 265mm(10.43in)
Bearing: 2BB
Feature:
- High voltage
- High performance programmable digital coreless standard servo
- High-precision Taiwan-made steel gears with hard anodizing
- Full CNC aluminium Shell structure
- Dual ball bearings
- Waterproof
Package included:
1 x JX CLS-HV7332MG 32KGHV Coreless Servo
