Main Features:
- Naze32 brushed flight controller includes integrated DSM2 receiver
- Adopted STM32 F103 chip
- The open source flight controller provides easy access to parameters adjustment with GUI of CleanFlight Configuration and BaseFlight Configuration
- Firmware upgradable via Micro USB port
- 5.8G 40CH ( with RaceBand ) FPV transmitter, 1/3 inch 800TVL 150 degree FOV CMOS camera, antenna, all-in-one, NTSC / PAL switchable
Channels:
Band A: 5865, 5845, 5825, 5805, 5785, 5765, 5745, 5725
Band B: 5733, 5752, 5771, 5790, 5809, 5828, 5847, 5866
Band E: 5705, 5685, 5665, 5645, 5885, 5905, 5925, 5945
Band F: 5740, 5760, 5780, 5800, 5820, 5840, 5860, 5880
Band R: 5658, 5695, 5732, 5769, 5806, 5843, 5880, 5917
Differences between T1 and T2
Their wheelbase and configuration of the frame are different.
T1 has a wheelbase of 95mm, and its shape resembles a beetle. However, the wheelbase of T2 is 85mm, and its frame is square.
Specification
General |
Brand: JJRC
Type: Frame Kit |
|---|---|
Dimension and Weight |
Product weight: 0.045 kg
Package weight: 0.210 kg Product size (L x W x H): 9.50 x 9.50 x 0.40 cm / 3.74 x 3.74 x 0.16 inches Package size (L x W x H): 16.00 x 16.00 x 9.00 cm / 6.3 x 6.3 x 3.54 inches |
Package Contents |
Package Contents: 1 x Airframe ( including Carbon Fiber Frame, Aluminum Posts, Motor Coils ), 1 x 5.8G 800TVL 40CH 25mW AIO FPV Camera, 4 x MD8520 Motor, 4 x Motor Coil, 4 x Orange Propeller, 4 x Black Propeller, 1 x 3.7V 600mAh 20C Battery, 1 x USB Charging Cable, 1 x Propeller Puller, 1 x Chinese-English Manual |
We do not accept any responsibility or liability for misuse of this or any other product. All our products are extensively tested to comply with rigorous and strict QC standards. For certain products (e.g. toys, knives, etc.), we recommend proper supervision as we cannot be held liable for misuse or accidents.
These toys contain small parts, not for children under 3 years in case of swallowing or choking . We do not accept any responsibility or liability for misuse of this or any other product.
