Inservos H1700HS-HV tail servo aer all intelligent digital programmable servos. They are not only light, but also with higher thermal efficiency. It use the lightest metal-magnesium alloy.
With the same size, each servo can be reduced 3g, four reduced 12g. The output shaft is 6mm. In the past this configuration is used in standard 50g servos. Thus, torque output is more stable and smooth.
It can change the frequency(Broadband 1520μs / Narrowband 760μs), can set it deadband(0.8μs-3μs). It can easily replace the gears. It uses 100,000 times long life potentiometer. It allows you to revive your plane and 200/250/300/350/450 3D helicopter.

Description:

Name: Micro Servo
Brand: Inservos
Model: H1700HS-HV
Type: Programmable 12-Bit Resolution Digital Circuit
Working Frequency: 1520us/333Hz 900-2100us
Torque: [email protected] [email protected]
Speed: 0.06sec/60°@6.0V 0.05sec/60°@7.4V
Application: 3D Helicopter Tail
Ball bearing: Twin ball bearings
Potentiometer: Rotate 360 degrees 100,000 times life
Motor: Φ12x15mm Coreless
Gear: All metal gears
Case: Lightweight Magnesium alloy center case
Size: 23.2*12.1*27mm(L*W*H)
Operating Voltage: DC4.5V-8.4V

Features:

* Lightest metal-magnesium alloy case. 1/3 lighter than aluminum, but cooling
efficiency is higher.
* 360 revolving potentiometer, high precision, long life.
* Intellingent can be programmed.
* Digital circuit. Fast response and excellent output performance.
* Double ball bearing.
* Output shaft is Φ6mm Torque output is more stable and smooth.
* All metal gears.
* Wide working voltage.

Package included:

1 x Micro Tail Servo H1700HS-HV
1 x Gear Arm Set
1 x Screws Set
