Specification:
Brand name: iFlight
Item name: Tachyon T1108 Micro Brushless Motor
KV: 5000KV 6000KV
Configu-ration: 9N12P
Stator diamter: 11mm
Stator length: 8mm
Shaft diameter: 2mm
Motor dimension (Dia.*Len): φ14.3*16.25mm
Weight(g): 9.3g(included wire)
5000KV:
Idle current(6)@6V(A): 1.0
No.of cells(Lipo): 2~4S
Max continuous power (W) 180S: 214.1
Internal resistance: 203mΩ
Max current(180S): 13.38A
Max Effciency current: (1.86-4.8A)>81%
6000KV:
Idle current(6)@6V(A): 1.1
No.of cells(Lipo): 2~3S
Max continuous power(W)180S: 228.1
Internal resistance: 160mΩ
Max current(180S): 19.01A
Max Effciency current: (3.3-8.28A)>81%
Package Included:
1X Tachyon T1108 Micro Brushless Motor
Package Included:
1X Tachyon T1108 Micro Brushless Motor
