iFlight SucceX PDB 2-8S 330A w/ 5V 12V BEC for RC Drone FPV Racing Multi Rotor

The Succex Power distribution board is designed for high voltage and high current applications. It consists of 2+2+3+3 layers of heavy copper to sustain maximum current demand. This PDB can sustain up to maximum total 330A. Also features 12V 3Amp and 5V 3Amp regulators with a maximum of 8S (36V) input.

In addition, it can also collect the signal port of each single ESC to an 8pin port, which can be directly inserted to the iFlight SucceX series flight control, to provide the most convenient and efficient flight experience.

Description:

Brand name: iFlight

Item name: SucceX PDB 2-8S

Input Voltage: 2-8S (5-36V)

BEC: 2-5S: 5V 3A/12V 3A

5-8S: 5V 2.5A/12V 2A

Mounting hole distance: 30.5 * 30.5 mm

Dimension: 36 * 36 mm

PDB: 4*70A Max.4*82.5A

Current Sensor 330A

SCALE: 100 (1 / 10mV / A)

Telemetry output: support

Weight: 8.7 grams

Features:

Support dual BEC output

Integrated TX telemetry port and motor signal port

The current sensor supports up to total 330A

High voltage and high current resistance

Integrated motor signal, current, telemetry, power supply ports on an 8-pin port

Package included:

1 x iFlight SucceX 2-8S PDB

1 x connecting cable set
