iFlight Revobee32 V2 F4 Flight Controller /w PDB OSD LC Filter Barometer BEC for RC Drone

Specification:
Brand name: iFlight
Item name: Revobee32 V2 F4 Flight Controller
Firmware: Betaflight, OMNIBUSF4FW (OBFW) 3.4
Voltage input: 3-6S Lipo
Size: 36x36mm
Mount holes: 30.5x30.5mm
Weight: 12.4g

Support SBUS, IBUS, DSMX, SUMD Receiver

Revobee32 V2 supports 3-6s LIPO direct input, build in hall Current Sensor and Power Filter too.

The on Board PDB is tweaked by using 12-Layer PCB design.

Modifications on v2:

-Tantalum Capacitors can be added to the board (not included)

-Solder pads added for SmartAudio and Camera Control (next to Video pads)

-The orientation of IMU FPC optimized

-Gyro ribbon cable redesigned to fit without extending outside the board

-Added an 8v BEC and LC Filter for the camera and VTX power

-This board now has 5 UART ports

Features:

-STM32 F405 MCU, Runs Betaflight firmware(supported from v3.2)

-ICM20608 Over SPI Bus in damping box. (optional MPU6000)

-30.5x30.5mm Mounting holes

-Supports Lipo direct plugin (3-6S)

-Supports 5V 1A BEC output (Buck)

-Supports 8V 1A BEC with LC filter output for the camera and VTX(Buck)

-STM32 controls OSD chip over SPI in DMA mode (Betaflight OSD)

-Built-in hall Current Sensor

-Built-in Professional Level PDB

-More caps to reduce power noise.

Package Included:

1 x Revobee32 V2 F4 Flight Controller
