Specification:
Item name: iFlight CineBee 75HD 2S whoop
Total Dimensions: 110x93x30mm
Frame Wheelbase: 75mm
Bottom & Top Plate Thickness: 1mm
Standoff height: 22mm
Build Weight: 64.4g (without battery, receiver)
Connector: XT30
Support Battery: 2S
Flying Time: over 3mins (battery recommend: 2S 420 mAh)
SucceX Micro 16x16 F4 Flight Control
SucceX Micro 12A 4in1 BlheliS ESC
SucceX Micro 200mW switchable VTX
iFlight 1103 11000KV 2S motors (1.5mm shaft)
Caddx.us Turtle v2 HD FPV Cam
Receiver: Without Receiver/ FS-A8S V2/ Frsky XM+/ Frsky R-XSR/ DSM2 DSMX Receiver (option)
Gemfan 1635 40mm 3-blade 1.5mm props
iFlight Prop Guards 40mm
Features:
- ultra-light but high performance
- JELLOFREE durable carbon/plastic construction
- no props or prop guards in view
- upgradeable, versatile, futureproof
SD card insert and ejection:
-The HD cam PCB is conveniently placed under the frame, protected by a cover.
-To insert or eject the SD card, please push in the SD card and gently slide beside the security plastic guard.
Cam- and VTX control implementation:
-Both Cam and VTX can be conveniently setup on your radio and in your OSD.
Package included:
1x iFlight CineBee 75HD Frame Kit
1x SucceX Micro 16x16 F4 Flight Control
1x SucceX Micro 12A 4in1 BlheliS ESC
1x SucceX Micro 200mW switchable VTX
4x iFlight 1103 11000KV 2S motors
1x Caddx.us Turtle v2 HD FPV Cam
1x Without Receiver/ FS-A8S V2/ Frsky XM+/ Frsky R-XSR/ DSM2 DSMX Receiver (option)
4x Gemfan 1635 40mm 3-blade 1.5mm Props
4x iFlight Prop Guards 40mm white
2x iFlight 10*100mm magic battery straps black
1x set of accessories
