Specification:
Item Name: IDC-588G-WiFi
Interface Type: CIS/SD/UART/2S/AudioCodec
Storage format: .H264
Supply voltage: 3.8V-5.5V (±10%)
Module current: 380mA (measured at 5V)
Video CIS: Input 640x480p@25, data bit width 10bit, frame valid, line valid signal polarity configurable
Video output: 640x480p@25
Antenna type: external antenna
Product size: 37.75mm (length) x 18.85mm (width) x 5.6mm (height)
Protocol/Standard: IEEE802.11b, IEEE 802.11g, IEEE802.n (1T1RModes)
Frequency range: 2.400~2.4835GHz
Channel: 1~11 (USA, Canada), 1~13 (Europe), 1~14 (Japan)
Modulation mode: · 802.11b: DSSS (CCK, DQPSK, DBPSK)
802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM)
Transmit power: 802.11b/g/n: 17±1dbm
Environmental requirements: Operating temperature: -10 ° C -60 ° C
Working humidity: 10%-90% RH without condensation
Package included:
1 x IDC-588G-WiFi 5.8G 40CH AV FPV Receiver Module for Mobile Phone
Package included:
1 x IDC-588G-WiFi 5.8G 40CH AV FPV Receiver Module for Mobile Phone
