iCharger 406 DUO 1400W Dual CH Port 6s Lipo Battery Balance Charger Discharger

The iCharger 406 DUO is a nicely refined, easy to use charger for your work bench or for use at the field. It has an easy to use knob for selecting the charge/discharge program and a very informative color screen that's also tilt adjustable.

As the name suggests it has two outputs for simultaneous or synchronized charging. An impressive 1400W charge capacity shared between the two outputs means you can charge those 6s high capacity packs quickly and safely at the field. It has a balance charge and stand alone balance function to keep your packs in the best condition and audible warnings with flashing messages on the screen should the charger sense any faults.

You can charge your phone or other USB compatible devices with the 1A 5V USB charger but rest assured, it has a built in over current protection.

This charger is very versatile allowing you to charge LiPo, LiLo, LiFe, NiMh, NiCd, PB and NiZn batteries. It also features charge, discharge, storage charge functions and upgradeable firmware through your PC (Drivers included in the CD instructions).

A very comprehensive and practical charger for the hobbyist who needs all the gadgets.

Description:
Brand:Icharger
Item:406 DUO Balance Charger
Input voltage range: 10.0~30.0VDC
LiPo/LiIo/LiFe: 1~6s
NiCd/NiMH battery cell count: 1~18s
Pb battery cell count: 1~15s
Max input current limit: <60A, CH1/2<47A
Max charge/discharge current: 70A@Syn. Mode 40A@Asyn. Mode
Max charge power capacity: 1400W (Channel 1000W @input > 23.5V)
Max discharge power capacity: 140W (Channel 80W)
Max regenerative discharge power capacity: 1400W (Channel 1000W)
Max extra discharge power capacity: 2000W (Channel 1000W @25V/40A)
Max current drain for balancing: 2.4A@Syn. Mode 1.2A@Asyn. Mode
USB charging port: 5V/1A(current-limiting protection 1.2A)
Usage:For,LiPo, LiLo, LiFe, NiMh, NiCd, PB and NiZn batteriesbattery,phone,or other USB compatible devices

Features:
- Dual channel output
- Up to 30V input
- Uses synchronous DC/DC converter technology
- 9 Multi-discharge features
- Anti-sparking protection
- Internal temperature protection
- Reversed polarity protection for input and output
- Flip up 2.8-inch LCD color screen
- Easy to use programming knob

Package Included:
1 x iCharger 406 DUO
1 x Power cable with EC5 Connector
2 x Charging cable with two banana plugs
2 x Balance board cable
2 x Balance boards
