Overview:

1.Full Aluminium Alloy Appearance Design,Solid & Well-made.Built-in Cooling fan for easy heat dissipation. 4.3 inch Color LCD Disply Touch Screen, Easy Reading and Operation

2.AC/DC Dual Input,High Power Circuit,Max Charing Power 420W, Max Charging current 20A.

3.Practical for variety of batteries.1-8s Lilon/LiPo/LiFe/LiHV,1-20cell Nicd/NiMh, 2-24V PB battery. Smart Battery I,II,III.

4.Multi-function: Balance Charge, Discharge,Terminal Voltage Control,Lithium Battery Capacity & Voltage Checking, Battery Internal Resistance Checking, Individual Cell Voltage Calibration,Data Storage and Loading,Charging Status Graphic Photo Display, Digital DC Power Supply 5-25V ,0.1-20A, USB DC Output 5V 2.1A,

5.Users Could Set The low input voltage, Capacity Limit, Temperature Threshold and Processing Time Limit Which Makes the Charger Safe to Use.

Features:

1.4.3 " Color LCD Disply Touch Screen, easy reading and operation

2.Full Aluminium alloy Appearance Design facilitate heat dissipation,

3.Built in cool fan, Good Cooling System.

4.With rubber pads, prevent sliding and the air can circulate.

5.AC/DC Dual Input. 420W Independent output

6.Support New LIHV High Power Battery and Smart battery.

7.Automatic identification of Li-Po batteries cells.

8.Battery management check battery capacity and voltage balancer. 8 Memories Data

9.Soft switching is also introduced can reduce radiation interference

10.Built-in PFC can improve the energy consumption from mainpower grid evidently

11.Support USB DC Output 5v/ 2.1A

12.Support for firmware upgrades

Specification:

Input AC 100-240V / DC 10-30V

Charge power: 420W

Discharge power:25W

Charge current range:0.1-20A

Discharge current range:0.1-5A

Digital DC Power:5-25V, 0.1-20A

Lilon/LiPo/LiFe/LiHV cell count :1-8cells

NiMH/NiCd: 1-20cells

Current drain for balancing: 500mA/cell

PB: 2-24V

Smart Battery: I/II/III

Dimension: 15.6*14.3*7cm

Net Weight:1.008kg

Gross Weight:1.52kg

Packaging Included:

1 X HT208 Charger

1 X DC Cord

1 X Charge Cable

1 X Charging board with pin cord

1 X AC Cord
