Description:
Setting: general settings such as Buzzer volume, Low input voltage, balance speed, Max charging power. Besides
Memory: save up to 8 operation data.
Monitor: checking battey capacity ,voltage, Internal Resistance, balancer.
Calibration: calibrate battery cell voltage.
Features:
-AC/DC Dual Input.
-4.3" Color LCD touch screen display for easy operation and convenient to use.
-Full Aluminium beautiful Appearance Design, Built in cool fan, Good Cooling System.
-With rubber pads, prevent sliding and the air can circulate.
-3 independent Port which can charge 3 different kinds of batteries simultaneously.
each port max charging power up to 200W, max charging current up to 20A.
-Automatic identification of Li-Po batteries cells.
-Support LIHV High Power Battery and Smart Battery.
-Battery management check battery capacity, voltage and balancer.
-Memory function save up to 8 operation data.
-5V 2.1A USB DC power supply output.
-Built-in PFC can improve the energy consumption from mainpower grid evidently,
-Soft switching is also introduced can reduce radiation interference
-Support firmware upgrades
Specifications:
Input Voltage:AC100-240V/DC10-30V
Charger Circuit Power:200W*3
Discharger Circuit Power:25W*3
Charger current range:0.1-20A*3
Discharge Current Range: 0.1-5A*3
Current Drian for Balancing Port:500mA/cell
Digital DC power:5-27V ,0.1-20A
Lilon/LiPo/LiFe/LiHV:1-6cell*3
Nicd/NiMh:1-15cell*3
PB: 2-20V*3
Smart battery: I/II/III*3
Demension:L27.35*W14.3*H7cm
Net Weight:1.12Kg
Gross Weight:2.38kg
Tips: Built-in AC high power charger naturally run hot,although with built-in fan, you need pay attention to the temperature,if prolonged use,especially in discharge modle,the internal AC adapter in a risk of damage.
if serious heat, it is better to place an external fan for heat radiating to prevent from damage. or use DC input to avoid problem.
Package Included:
1 x HT206 TRI Charger
1 x DC Cord
3 x Charging cable
3 x Charging Board with pin cord
1 x AC Cord (EU Plug)
