Specification:

Input voltage: DC10-28V

Charge/Discharge power: 300W/20W

Charge/Discharge current: 0.05-20A

Lipo/Lilo/LiFe: 1-6S

NiCd/NiMH: 1-17S

Lead Acid(Pb): 2-24V

Dimensions: 140x95x27mm

Net weight: 350g

Feature:

1.Support Many Kinds of Battery

The charger can be used with Lipo, Lilo, LiFe, Ni-Cd, NiMH and Pb battery.

2.Flash Storage

The charger has a 16Mbit flash storage,which can log offline charge and discharge data in 36 hours.

3.Unique Lithium Battery Monitor Program

When you use other equipment to charge or discharge a Lithium pack,you can use the charger to monitor the per-cell voltages, battery temperature and process time. If any individual cell appears over-charged or over-discharged or the pack is too hot or the process has gone on for too long,the charge will generate an alarm sound and the related information will blink.

4.Data Storage

Convenient set of 10 battery profile memories that can be saved and loaded by number,

5. Battery Interior Resistance Measurement

The charger can not only measure the internal resistance of the battery pack, and also can measure the per-cell internal resistance (only available for lithium battery).

6.Perfect Protection Function

The charger has protection for reversed polarity(input or output), low input voltage, battery temperature, charging capacity and time overrun.

Packaging included:

1X Thunder 300W 20A charger
