Holybro Cleanflight Raceflight Betaflight STM32F303CCT6 32-bit Flight Control w/ OSD PDB Integrated
Specification:
. STM32F303CCT6(256kB flash) 32-bit processor
. MPU6050 Gyro/Accelerometer
. ATmega328P with Arduino Bootloader(minim OSD)
. MAX7456 Monochrome On-Screen Display(minim OSD)
. FTDI Cable Compatible Pinout(minim OSD)
. High quality, gold plated PCB
. Micro USB connector for programming
. Dimensions: 36x47.5x7mm (includes USB in height)
. Mounting Holes: 30.5mm square to center of holes
. Weight: 7g
Features:
. With FC, OSD, PDB all integrated.
. Only one VTX module is needed to make a complete set of FPV Racing Drone.
. Minim OSD integrated; MWOSD Firmware preloaded; OSD Config port available;
OSD interface highly customizable according to you own needs.
OSD interface highly customizable according to you own needs.
. 2 oz Copper PCB ensures the 120A Maximum Continuous Current.
. Dedicated Boot button for easy firmware flashing.
. Reinforced solder pads for trouble-free direct soldering.
. Extremely low profile design.
. Input voltage 7v to 42v. Power the board directly from flight pack up to 6S (on 'BAT' pad only!).
. PDB Maximum Continuous Current 120A
. VIN + VBAT merged - A single wire to power the board will provide voltage input and Telemetry/OSD voltage data.
. Filtered voltage output - output 5v 800mA (and 3.3v 150mA where applicable) to power peripherals
such as GPS, RX, BLACKBOX. 5v/3.3v RX selectable.
such as GPS, RX, BLACKBOX. 5v/3.3v RX selectable.
. Cleanflight support (RACE target).
. BLHeli flashing supported by hardware
. Raceflight ready
. Betaflight ready
Package included:
. 1x Kakute Flight Controller
. 1x Quick Start Guide
. 1x 80mm XT60 connector wire
