Specifications:
- Interchangeable ground and air ends
- Adjustable output power ( 100mW maximum )
- 2-way full-duplex communication through TDM
- MAVLink protocol framing
- Frequency Hopping Spread Spectrum ( FHSS )
- Configurable duty cycle
- Receiver sensitivity: -117dBm
- Open-source SiK firmware
- Can be configured with Mission Planner and APM Planner
- Supply voltage: 3.7 - 6V DC ( from USB or DF13 connector )
- Transmitter current: 100mA at 20dBm
- Receiver current: 25mA
- Serial interface: 3.3V UART
- Transmitter size: 2.5 x 5.2 x 1cm ( not including the RP-SMA connector )
- Transmitter weight: 13g x 2
- Antenna length: 11cm
- Compatibility: PIXHAWK flight controllers; 200 - 900mm multicopters
- Interchangeable ground and air ends
- Adjustable output power ( 100mW maximum )
- 2-way full-duplex communication through TDM
- MAVLink protocol framing
- Frequency Hopping Spread Spectrum ( FHSS )
- Configurable duty cycle
- Receiver sensitivity: -117dBm
- Open-source SiK firmware
- Can be configured with Mission Planner and APM Planner
- Supply voltage: 3.7 - 6V DC ( from USB or DF13 connector )
- Transmitter current: 100mA at 20dBm
- Receiver current: 25mA
- Serial interface: 3.3V UART
- Transmitter size: 2.5 x 5.2 x 1cm ( not including the RP-SMA connector )
- Transmitter weight: 13g x 2
- Antenna length: 11cm
- Compatibility: PIXHAWK flight controllers; 200 - 900mm multicopters
Specifications
General |
Brand: Holybro
Type: Antenna,Transmitter |
|---|---|
Dimension and Weight |
Package weight: 0.148 kg
Package size (L x W x H): 10.80 x 7.50 x 4.30 cm / 4.25 x 2.95 x 1.69 inches |
Package Contents |
Package Contents: 2 x Transmitter, 2 x Antenna, 1 x USB Cable, 1 x Android OTG Adapter Cable, 1 x 6-wire PIXHAWK Connector Cable, 1 x 6-to-5-position APM / PX4 Connector Cable |
