Main Features:
- 15 programmable parameters, like start force, drag brake rate and etc.
- Adjustable PWM frequency and advanced freewheeling technology
- Waterproof and dustproof, it can be used on all-terrain vehicles
- Excellent braking performance thanks to the fine-tunable drag brake rate
- Built-in switch mode BEC with 6A maximum output and 6 - 7.4V adjustable voltage, makes it possible to run various standard servos, high-voltage servos as well as other peripherals
- Separate PRG / FAN port, which can be used to power an external fan and get better cooling performance
- The port can also be connected to the LED program box ( included ) to configure the parameters

Specifications:
Item: QuicRun WP Crawler Brushed ESC
Compatibility: 1/8 and 1/10 RC Cars, Trucks
Waterproof: yes
Dustproof: yes
Continuous / peak current: 80A / 400A
Input voltage: 2 - 3S LiPo / 5 - 9S NiMH
BEC output: Switch Mode: 6V / 7.4V at 3A; 6A at maximum
Input connector: XT60
Output connector: no
Firmware upgrade: no
Applications: 540 / 550 / 775 brushed motors; 1/8 1/10 rock crawlers
KV rating / T count:
Limit with 2S LiPo / 6S NiMH: 10T or more; RPM less than 30000 at 7.4V
Limit with 3S LiPo / 6S NiMH: 16T or more; RPM less than 20000 at 7.4V
