HobbyEagle A3 Pro 3 Axis Gyro Flight Controller Stabilizer For RC Airplane
Overview:
The new A3 Pro is a high-performance, powerful 6-axis gyroscope and balance designed specifically for RC Airplane. It can be used on almost any size and type of fixed-wing aircraft and can make handling of the aircraft easier and more comfortable.
Specification:
Brand Name: HobbyEagle
Item Name: A3 Pro
Main Controller: 32-bit MCU
Sensors: High-precision 3-axis gyroscope and 3-axis accelerometer
Gyroscope Scale Range: ±2000dps
Accelerometer Scale Range: ±4g
PWM: 920μs - 2120μs with 1520μs center length / 50-333Hz
Input Voltage: 4.8V - 8.4V
Operating Temperature: - 10â - 20â
Size: 43x27x14mm
Weight: 10g (excluding wires)
Features:
32-bit processor, high-precision 6-axis MEMS sensor, complete hardware design and stable new firmware for more reliable performance.
Supports 6 different flight modes: Gyro-off mode, normal mode, anti-lock mode, trainer mode, anto-level mode and auto-hover mode.
Compatible with most traditional receivers, supporting standard PPM single line receivers and Futaba S.Bus and S.Bus 2 single line receivers.
English Manual,
Package Included:
1x HobbyEagle A3 Pro 3 Axis Gyro Flight Controller Stabilizer
Sensors: High-precision 3-axis gyroscope and 3-axis accelerometer
Gyroscope Scale Range: ±2000dps
Accelerometer Scale Range: ±4g
PWM: 920μs - 2120μs with 1520μs center length / 50-333Hz
Input Voltage: 4.8V - 8.4V
Operating Temperature: - 10â - 20â
Size: 43x27x14mm
Weight: 10g (excluding wires)
Features:
32-bit processor, high-precision 6-axis MEMS sensor, complete hardware design and stable new firmware for more reliable performance.
Supports 6 different flight modes: Gyro-off mode, normal mode, anti-lock mode, trainer mode, anto-level mode and auto-hover mode.
Supports 3 Wing Types: Standard, Delta-wing (Flying-wing) and V-tail.
Supports remote total sensitivity control.
Provides Sub Trim and Travel Limit.
Ailerons, elevetor, directions, three-axis sensitivity independent regulation.
6 working frequencies for servos: 50Hz, 65Hz, 165Hz, 200Hz, 270Hz and 333Hz.Supports remote total sensitivity control.
Provides Sub Trim and Travel Limit.
Ailerons, elevetor, directions, three-axis sensitivity independent regulation.
Compatible with most traditional receivers, supporting standard PPM single line receivers and Futaba S.Bus and S.Bus 2 single line receivers.
English Manual,
Package Included:
1x HobbyEagle A3 Pro 3 Axis Gyro Flight Controller Stabilizer
