HGLRC XJB F428-TX20 F4 Flight Controller 28A 2-4S Blheli_S ESC 0/25mW/100mW/250mW Switchable FPV VTX 20x20mm

Specification:
Model: HGLRC XJB F428-TX20
Weight: 6.5g
Usage: for 65mm-250mm Frame Kit

Micro F4 Flight Controller Board ( D-Shot Version)
MPU: MPU6000-SPI
CPU: STM32F405RGT6, dual 8K.
Black Box: Flash 16M
Input Voltage: 2-4S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A
Size: 25x25mm board, 20mm mounting holes (M2)
Weight:2.3g
Support Subs/PPM/DSMX receiver


28A 2-4S Blheli_S BB2 4 in 1 ESC:
Input Voltage: 2-4S Lipo battery
Constant Current: 28A
Peak Current: 35A
BEC Ouput: NO
Firmware: BLheli_S 16.5
Size: 27x27mm (main board)
31x31mm ( including pad)
Installing Hole: 20x20mm, M2
Weight: 4.2g
CPU: SILABS EFM8BB2 48MHZ
MOS Tube: TOP QUALITY MOSFET
Firmware: Betaflight 16.5
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, forward and reverse

HGLRC XJB-TX20 Mini FPV Transmitter
Output power: 0/25mW/100mW/250mW switchable
BAT: 7-24V,BEC 5V-3A
170mA----250mW
120mA----100mW
80mA----25mW
Video system: NTSC/PAL
Antenna: IPEX
Frequency: 5.8GHz 9 bands 72 channels, with Raceband: 5325-5945 MHZ
Size: 23*23mm(L*W),Hole:20*20mm
Weight: 2.2g


Package Included:
1x HGLRC F4 AIO OSD BEC Flight Controller Board
1x HGLRC 28A Blheli_S 4 In 1 ESC
1x HGLRC XJB-TX20 Mini FPV Transmitter
