HGLRC Titan Plus F460 & GTX585 Stack AIRBUS F4 Flight Controller OSD + Dinoshot 60A Blheli_32 ESC + GTX585 VTX
Description:
Brand name: HGLRC
Item name: HGLRC Titan PLUS F460-GTX585( 32bit 60A 4-in-1 ESC)
Weight: 31.2g
Usage: for 130mm-280mm frame kit
AIRBUS F4OSD Flight Control Board ( D-Shot Version):
MPU: MPU6000-SPI
CPU: STM32F405RGT6, Dual 8K.
Black box: Flash 16M
Input Voltage: 2-6S Lipo
Built-in Betaflight OSD to adjust PID
BEC output: 5V@3A
Size: 36x36mm board, 30.5mm mounting holes (M3)
Weight: 8.3g
Support Subs/PPM/DSMX receiver
DinoShot60A 3-6S 4-in-1 ESC BLHeli_32:
Input voltage: 3-6S lipo battery
Constant current: 60A
Peak current: 70A
BEC ouput: NO
Firmware: 32bit ESC with BLHELI_32 firmware
Size: 36x36mm (main board)
40x48mm (including pad)
Installing hole: 30.5x30.5mm, M3
Weight: 12.9g
CPU: STM32F051
MOS tube: TOP QUALITY MOSFET
Protocol: DSHOT1200/600/300/150/Oneshot125/42, MultiShotDamped mode
HGLRC GTX585 5.8G 48CH VTX:
Channel: 48CH
Output power: PIT/25mW/100mW/200mW/400mW/600mW switchable
Control mode: BFOSD control(RX)/button
BAT: 7-26V
BEC 5V-1A 240mA----400mW
Video system: NTSC/PAL
Antenna: MMCX
Size: 20*38mm(L*W)
Mouting hole:30.5*30.5mm
Weight: 10g
Package included:
1 x AIRBUS F4OSD flight controller
1 x Dinoshot 60A Blheli_32 4 in 1 ESC
1 x SH1.0 8PIN 60mm cable
1 x GTX585 48CH 25/100/200/400/600mW VTX
1 x MMCX antena
1 x bag of screws
