Specification:
Brand Name: HGLRC
Model: Batman220
Item Name: 220mm F4 5.8G FPV Racer
Wheelbase: 220mm
Arm Plate Thickness: 5mm
Bottom Plate Thickness: 2mm
Material: Carbon Fiber
Drone Version: BNF ( With Frsky XM+ Receiver & Without Battery)
Net Weight: about 306.3g
Drone Version: BNF ( With Frsky XM+ Receiver & Without Battery)
Net Weight: about 306.3g
| Flight Controller |
HGLRC F460 Flytower Spare Part FC Item Name: AIRBUS F4 OSD FC (D-Shot Version)
MPU: MPU6000-SPI
CPU: STM32F405RGT6, dual 8K
Black Box: Flash 16M
Input Voltage: 2-6S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A
Size: 36x36mm
Mounting Hole: 30.5x30.5 ( M3)
Weight: 8.3g
Support SBUS/PPM/DSMX receiver
|
| Brushless ESC |
HGLRC F460 Flytower Spare Part ESC Item Name: 60A BLHeli_32 3-6S 4 In 1 ESC
Input Voltage: 3-6S Lipo battery
Con. Current: 60A-4S / 50A-5S / 40A-6S
Peak Current: 70A
BEC Ouput: NO
Firmware: 32bit ESC with BLHELI_32 firmware
Size: 36x36mm (main board )
40x48mm ( including pad)
Mounting Hole: 30.5x30.5mm, M3
Weight: 12.9g
CPU: STM32F051
MOS Tube: TOP QUALITY MOSFET
Protocol: DSHOT1200/600/300/150/Oneshot125/42 , MultiShotDamped
|
| FPV Transmitter |
Item Name: HGLRC GTX585 5.8G 48CH PIT/25/100/200/400/600mW VTX Model: GTX585
Output power: PIT/ 25/ 100 /200/ 400/ 600mW Switchable
Control mode:BFOSD control(RX) button BAT: 7-26V BEC: 5V-1A 240mA----400mW Video system: NTSC/PAL Antenna: MMCX Frequency: 5.8GHz 6 bands 48 channels, with Raceband: 5362-5945 MHZ Size: 20x38mm(L*W) Mounting Hole: 30.5x30.5mm Weight: 6.8g |
| Brushless Motor |
Item Name: HGLRC HF2306 2450KV Motor
KV: 2450KV
Stator Diameter: 23mm
Stator Thickness: 6mm
No.of Stator Arms: 12S
No.of Rotor poles:14P
No-load Current(A/10V):1.6A
Motor Resistance:49mΩ
Max Continuous Current:41.4A
Max Continuous Power:660W
Weight:32g
Rotor Diameter:28.72mm
Shaft Diameter:5mm
Body Length:16.1mm
Overall shaft Length:29.7mm
No.of Cells(Lipo):4S~5S
Wire type:20AWG 110mm
|
| FPV Camera |
Model: HGLRC XJB-ELF 600TVL 1/3 CCD Camera
Image Sensor: 1/3 SONY Super HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.3mm Lens
FOV: 120 degree(2.3mm)
Signal System: PAL
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000
AutoGain Control(AGC): YES
Back light compensation(BLC): YES
Min.illumination: 0.01Lux/1.2F
WDR: D-WDR
DNR: 2DNR
Day/Night: Color / Auto / B&W
Power: DC 5 to 36V
Net weight: 5.2g
Dimensions: 19mm * 19mm * 19mm
|
| Propeller |
Item Name: HGLRC 5042 5 Inch 3-Blade Propeller Color: Clear White Quantity: 3 CW & 3 CCW |
| Receiver |
Item Name: Frsky XM+ Receiver CH: Up to 16CH from SBUS (1-15ch for PWM,16ch RSSI for FC) Operating Voltage Range: 3.7~10V Operating Current: 30mA @5V Operating Range: Full range With RSSI output on board: Analog 0~3.3V Firmware Upgradeable Version: International Version Compatibility: FrSky D16 mode Dimension: 21.5*12*3.5mm(L x W x H) Weight: 1.6g |
Package Included:
1x HGLRC Batman220 F4 FPV Drone ( BNF Version)
1x Battery Strap
1x HGLRC Pagoda 5.8G 5dBi RHCP Antenna
