Specification:
Brand Name: HGLRC
Item Name: HGLRC Forward 2207 1775KV Motor & 50A BL_32 ESC Combo
Forward 2207 1775KV Motor
Forward 2207 1775KV Motor
Motor KV: 1775KV
Stator Diameter: 22mm
Stator Thickness: 7mm
No.of Stator Arms: 12S
No.of Rotor poles: 14P
No-load Current(A/10V): 0.89A
Motor Resistance: 62mΩ
Max Continuous Current : 34A
Max Continuous Power: 680W
Weight(Excluding Cable): 30.7g
Rotor Diameter: 27.5mm
Shaft Diameter: 5mm
Body Length: 17.7mm
Overall shaft Length: 30.9mm
No.of Cells(Lipo): 5~6S
Recommend ESC: 40~60A
Recommended Prop(inch): 5 Inch
Wire Szie : 18AWG 150mm
Quantity: 4 PCS
Quantity: 4 PCS
Forwad FD50A 50A BLHeli_32 ESC
Input Voltage: 2-6S Lipo battery
Constant Current: 50A
Peak Current: 60A
BEC Ouput: NO
Firmware: BLHELI_32
Size: 42x10x6.4mm
Weight: 5.2g
CPU:STM32F051
MOS Tube: TOP QUALITY MOSFET
Protocol:DShot 150/300/600/1200, Oneshot125, Oneshot42, Multishot
Package Included:
4x Forward 2207 1775KV Motor
4x Forward 50A ESC
Package Included:
4x Forward 2207 1775KV Motor
4x Forward 50A ESC
