Specification:
F4 FLAME V2 Flight Controller:
Brand Name: HGLRC
Item Name: 30.5x30.5mm F4 Flame V2 Flight Controller
Chip: CPU STM32F405RGT6 , dual open 8K, MPU 6000-SPI
BEC output: 5V/3A
Direct welding ESC PDB
Built-in current sensor
Input voltage: 2-6S Lipo
Board thickness: 1.6MM
Black box: FLASH 16M, large capacity storage
Built-in BETAFLIGHT OSD to achieve remote control PID parameters
copper foil thickness: 2OZ * 8
Maximum current: 300A
Hole mounting size: M3 30.5 * 30.5mm
Buzzer / programming LED / voltage monitoring / BLHELI-S ESC programming
Support SBUS / PPM / DSMX and other mainstream mainstream receiver
Weight: 11.9g
T-Rex 35AMP ESC BLHeli_32:
Brand name: HGLRC
Item name: T-Rex 35AMP ESC BLHeli_32
Input voltage: 3-6S Lipo
Work current: 35A
Burst Current: 45A
BEC: NO
Size(mm)L*W: 27*15
MOS: ALL N FET, TOSHIBA COMPANY
Copper: 3OZ*6 18OZ
Firmware: 32bit ESC with BLHELI_32 firmware
Protocol: DSHOT1200/ DSHOT600/ 300/ 150/ Oneshot125/ 42, MultiShot Damped mode
Weight: 3.4g(no include wire)
MCU: STM32F051
To download the installation package of BLHeli_32 Android APP please click here.
To download the installation package of BLHeli_32 Android APP please click here.
Features:
-Supported Protocols: Analog Signals - MULTISHOT, ONESHOT42, ONESHOT125/ Digital Signals - DSHOT150, 300, 600, 1200.
-Imported Japanese Toshiba MOSFETs and Japanese Murata Ceramic Capacitors.
-3oz High-TG PCB board: Reduces Heat Soak and improves system efficiency.
-Silicone Signal and Power Wires provides high heat-resistance and flexibility.
-Ultra-Small / Ultra-Light footprint.
Package included:
1x F4 FLAME V2 Flight Controller
4x T-REX 35AMP BLHeli_32 3-6S ESC
