Specification:
Brand Name: Happymodel
Model: Mobula7 HD
Item Name: 75mm Wheelbase 2-3S Brushless Whoop FPV Racing Drone
Wheelbase: 75mm
Receiver ( Optional): Compatible Frsky NON-EU Receiver
Compatible Flysky Receiver
Compatible DSM2/DSMX Receiver
Without Receiver
Size: 98mm*98mm*45mm
Weight: 48g (without battery)72g ( with battery )
| Crazybee F4 PRO V2.0 Flight Controller |
Item Name: Crazybee F4 Pro V2 FC MCU: STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI connection) Board size: 28.5 * 28.5MM Power supply: 1-3S battery input (DC 3.5-13V) Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready Built-in Receiver ( Diffirent version having diffirent receiver, without receiver version doesn't have rx) Built-in Betaflight OSD(SPI Control) Built-in Current meter Max 28A Current meter scale set to 1175 Built-in 5V 1A Buck / Boost with LC filter Built-in voltage detection Firmware
(Frsky version) CRAZYBEE F4FR PRO V2.0 Firmware target: CrazybeeF4FR
(Flysky version) CRAZYBEE F4FS PRO V2.0 Firmware target: CrazybeeF4FS
(DSM2/DSMX version) CRAZYBEE F4DX PRO V2.0 Firmware target: CrazybeeF4DX
(No RX version) CRAZYBEE F4 PRO V2.0 Firmware target: CrazybeeF4DX
|
| Onboard 5A 4 In 1 ESC |
MCU upgraded to EFM8BB21
Power supply: 1-3S LiPo/LiPo HV (3.5v/13v)
Current: 5A continuous peak 6A (5 seconds)
Support BLHeliSuite programmable
Factory firmware: S_H_50_REV16_7.Hex
Default protocol: DSHOT600
|
| Onboard Frsky NON-EU receiver Version |
SPI BUS receiver
Frsky D8/D16 switchable
Compatible Non EU transmitter both D8 and D16 mode
Channels: 8ch or 16ch
Failsafe support
No ground interference ( Transmitter and receiver 1 m from the ground): 300m
|
| Onboard Flysky receiver Version |
SPI BUS receiver
Protocol: AFHDS and AFHDS-2A Switchable
Channels: 8ch(AFHDS) or 14ch(AFHDS-2A)
No ground interference ( Transmitter and receiver 1 m from the ground): 300m
Failsafe support
|
|
Onboard DSM2 / DSMX receiver version |
Serial bus receiver Protocol: DSM2/DSMX compatible Channels:6-9 (Depend on your radio) No ground interference ( Transmitter and receiver 1 m from the ground): 300m |
| EX1102 10000KV Motor |
Model: EX1102 KV: 10000KV Configu-ration: 9N12P
Stator Diamter: 8mm
Stator Length: 2mm
Shaft Diameter: Φ1.0
Motor Dimension (Dia.*Len) : Φ10.5*14.5mm
Weight: 2.7g
Support 1-3S Lipo |
| Propeller |
40mm 4-blade Propeller ( 4 CW + 4 CCW) |
| 5.8G 40CH 25-200mW VTX |
Output power: 25~200mw switchable
Frequency: 40CH
Input voltage: 3.3V 5.5V
Current consumption: 300mA(type)
Antenna: RG178 antenna
Frequency: 5.8GHz 5bands 40 channels
With Raceband
Smartaudio ready
Weight: 3g
|
|
CADDX Turtle V2 Camera |
Image sensor: 1/2.7" CMOS sensor
Horizontal: 800TVL
TV system: NTSC/PAL changeable
Video Resolution: 1080P@60fps / 1080P@30fps / 720@60fps
Power Input: DC 4.5-20V
FPV FOV: 155°
Recording FOV: 170°
Mini Illumination: 0.01lux
Image Resolution: 2 Megapixels
Lens: 1.8mm Turbo Eye Lens
Working Current: 380mA@5V/160mA@12V (low consumption)
OSD Menu: Yes (Support Voltage Display)
Video Files: MP4
Audio: Support
Electronic Shutter : PAL : 1/50-100,000 NTSC : 1/60-100,100
S/N Ratio: >60dB (AGC OFF)
Video Output: CVBS
Max Micro SD Card Supported: 8-64GB(need Class 10 or above, recommend Class 10/UHS-I/UHS-II)
Color: Red
|
| Lipo Battery |
Capacity:300mAh
Voltage:11.4v
Continuous Discharge Rate: 30C
Instantaneous discharge rate: 60C
Size: 65mmx18mmx11mm
Weight: 23g
Connector: XT30
|
Features:
- New Crazybee F4 PRO V2.0 AIO Flight controller 1-3s Lipo Compatible
- 2S for indoor Cine whoop mode
- 3S for outdoor Freestyle whoop mode
- Betaflight support , multi flight mode: ACRO/AIR/ANGLE
- The lightest 1102 brushless motor only 2.7g with double ball bearings
- Powerful and smoothly
- Betaflight OSD support ,easy to get RSSI, Voltage ,current from your goggles(DSMX version no RSSI output)
- Caddx turtle v2 + 1080p 60fps DVR ready
- Camera Angle adjustable
- VTX power switchable 25mw~200mw
- Smartaudio ready , change VTX bands, powers, channels via OSD
- Frsky Non-EU version support NON-EU Frsky transmitter D8/D16 compatible
- Flysky version support both AFHDS and AFHDS-2A protocol transmitter
- DSM2/DSMX version support DSM2 and DSMX compatible Spektrum transmitter
- No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc..
- Full telemetry function ready (Frsky Non-EU and Flysky version support)
- Special Breath light ready
- Real Bind and Fly version
- Compatible both for 2s-3s Lipo/LIHV
Package Included:
1x Mobula7 HD 75mm FPV Drone
4x 40mm 3-Blade Propellers ( 4 CW & 4 CCW)
1x 3S 11.4v 300mah 30C/60C battery
1x Propeller Disassemble Tool
1x Screwdriver
