HAKRC Betaflight F4 Flight Controller OSD Intergrated PDB 35 2-5S Blheli32 Bit DSHOT1200 Brushless ESC w/ LED


















Specification:
Brand name: HAKRC
Item name: F4 Flight controller Intergrated PDB + 4X 35A ESC

F4 Flight controller:
Firmware: BetaFlight 3.20 SD (3.20 SD version pick one of two PPM and LED. 3.17 SD version can compatible work PPM and LED together. )
OSD firmware version: BetaFlight OSD
MPU: MPU6000
CPU: STM32F405
Camera and VTX Voltage: 5V
Barometer: YES
Black box: YES
Work voltage: 2-4S LIPO
BEC: 5V/2A
Support receiver: PPM, SBUS, IBUS, DSM2
Size: 44x36mm
Weight: 9g

35A ESC
Con.Current:35A
Peak Current(5s): 40A
Input Voltage: 2-5 Cell LiPo
Microcontroller: STM32F051
Program: BLHeli32 bit
Integrated LED lamp, can change the color of the lamp
Size: 26x13x5 mm
Weight: 7g

Feature:
Highly integrated processor and sensor
Programmable LED strips
Monitor the battery port voltage and current.
Support for OneShot/DShot ESCs simplifies PID parameter adjustment and rapid feedback.
Supports SBus, SumH, SumD, Spektrum1024/2048, XBUS, IBUS, PPM receivers.(Built-in 5V and 3.3V buck)

Package Included:
1 x F4 flight controller integrated PDB
4 x 35A ESC
