GS-9018

Control System

Positive PWM control 1500 usec Neutral

Operation Voltage Range

4.8V ~ 6.0V

Operation Temperature Range

-20C°~ +60C°

Test Voltage:

At 4.8V

At 6.0V

Standing Torque

1.5kg.cm

1.7kg.cm

Speed

0.3 sec / 60 deg at no load

0.12 sec / 60 deg at no load

Idle Current

160mA at stopped

500mA at stopped

Running Current

180mA at no load

600mA at no load

Dead band width

8.0 μs

8.0 μs

Circle

15000 times

Operation Travel

60°±10°

Direction

Re-clock wise/ Pulse Travel 1500 to 2100 usec

Motor Type

Brush

Potentiometer Type

Direct Driver

Amplifier Type

Analog Control

Dimensions

23*12.1*21.4mm

Weight:

9g without splined horn

Ball Bearing

N/A

Gear Material

POM

Case Material

PC

Connector Wire Length

250mm

Connector Wire Gauge

26AWG heavy duty (JR Universal)

Package Included:
1X GOTECK GS-9018C Brush Micro Servo
1X screw set
