GEPRC GEP-QX5 195mm Carbon Fiber Frame Kit with XT60 PDB/BEC for RC Multirotor
Specification:
Brand: GEPRC
Item name: GEP-QX5 195mm Frame Kit
PDB: have
Material: Carbon Fiber
Wheelbase: 195mm
Size: 175 x 175mm
Main board: 4mm
Other board: 2mm
Weight: 65g(include Aluminum parts)
Recommended: (not included)
Flight Controller: F3 /Naze32/ CC3D
Motors: 2204/2205/2206/2305
ESC: 20A-30A
Propeller: 5inch
Battery: 3S 1300mAh ~ 4S 1300mAh
Features:
1. 3K high strength carbon board to ensure that the framework is strong
2. Extremely light, total weight less than 65g
3. Very low center of gravity, under the battery rack
4. 5 inch propeller, wheelbase 195mm
5. This is “X” layout, Between each arm is 90 degrees. Each direction is very flexible
6. The wind resistance is very small, but stay strong
7. Clear flexible LED taillights (need FC support)
8. The structure is strong, beautiful .
9. Integrated XT60 panels, save silicone line, to reduce weight
10. Camera angle adjustable, adjustable 60 degrees
11. The lens comes with fixed film, for the market of 95% CCD fixed lens
12. With a XT60 PDB, with BEC (5/12v output, max. 3A, 2A)
13. Custom 15MM, 30MM high strength non slip aluminum column
Package included:
1 x GEPRC GEP-QX5 195mm Frame Kit
