Description:
Apart from its sturdiness and light weight, this carbon fiber frame protects the motors and provides various choices of lens. It also comes with a PDB, a LED board, as well as an XT60 plug.
Main Features:
- 3K high strength carbon fiber
- GoPro base with 20 - 50 degree adjustable angle
- YFS screws, 12.9-grade hardness
- X configuration
- Support 28mm lenses, such as HS1190, HS1170, Swift and OVL Lens
- Wider motor protector base, fishtail-like, protects the motor from being crashed
- Adjustable lens mount, 0 - 60 degree
- Including PDB, XT60 plug, BEC 5V / 12V output
- With integrated tail LED board, can be controlled by flight controller or work independently with SCM
Specifications:
Model: GB180 Chimp
Weight: 92g
Wheelbase: 180mm
Arm length: 4 inches
Arm thickness: 4mm
Side board: 2mm
Other board: 1.5mm
Recommanded parts ( not included ):
Flight controller: F3 / Naze32 / CC3D
Motor: 2204 / 2205 / 2206 / 2305 / 2306
ESC: 20 - 30A
Propeller: 4 inch
Battery: 3 - 4S 1300mAh
Apart from its sturdiness and light weight, this carbon fiber frame protects the motors and provides various choices of lens. It also comes with a PDB, a LED board, as well as an XT60 plug.
Main Features:
- 3K high strength carbon fiber
- GoPro base with 20 - 50 degree adjustable angle
- YFS screws, 12.9-grade hardness
- X configuration
- Support 28mm lenses, such as HS1190, HS1170, Swift and OVL Lens
- Wider motor protector base, fishtail-like, protects the motor from being crashed
- Adjustable lens mount, 0 - 60 degree
- Including PDB, XT60 plug, BEC 5V / 12V output
- With integrated tail LED board, can be controlled by flight controller or work independently with SCM
Specifications:
Model: GB180 Chimp
Weight: 92g
Wheelbase: 180mm
Arm length: 4 inches
Arm thickness: 4mm
Side board: 2mm
Other board: 1.5mm
Recommanded parts ( not included ):
Flight controller: F3 / Naze32 / CC3D
Motor: 2204 / 2205 / 2206 / 2305 / 2306
ESC: 20 - 30A
Propeller: 4 inch
Battery: 3 - 4S 1300mAh
Specifications
Custom |
Brand: GEPRC |
|---|---|
General |
Type: Frame Kit |
Racing Quadcopter Parameters |
Wheelbase: 180mm |
Dimension and Weight |
Package weight: 0.120 kg
Package size (L x W x H): 21.00 x 20.00 x 4.00 cm / 8.27 x 7.87 x 1.57 inches |
Package Contents |
Package Contents: 1 x Frame Kit, 1 x PDB, 1 x LED Board, 1 x Battery Tie, 1 x XT60 Plug |
