Specification:
Brand: GDW
Model: DS396MG
| Bench tests reported values | |||
| Test Voltage | 6.0V | 7.4V | 8.4V |
| Speed | 0.128sec/60° | 0.10sec/60° | 0.093sec/60° |
| Torque | 9.0Kg.cm | 11.3Kg.cm | 12.9Kg.cm |
| Fast continuous operating current | 700mA | 850mA | 1000mA |
| Stall current | 1800mA | 2000mA | 2300mA |
| Dead Band Width | 3u | ||
| General Data | |
| Motor Type: | Coreless motor 15*15mm |
| Potentiometer Type: | Japan noble 220° |
| Chip type: | Digital |
| Weight: | 39±1g |
| Gear Material: | Iron copper gear |
| Structural materials : | Internediate metal |
| Horn Gear Spline: | 25T 5.92mm |
| Wire length: | 220±5mm |
| Wire Diameter: | 0.15mm* |
| Number of wire cores: | 30 |
Package included:
1*GDW DS396MG Servo
