Description:
The carbon fiber is popular among the RC hobbyists, because it excels in both light weight and sturdiness. Choose the durable material, and your beloved quadcopter will be your long-time companion!
Main Features:
- The full 3K carbon fiber airframe features a solid 2mm main plate and 4mm removable arms
- Custom aluminum hardware enables the quick replacement of arms in race
- Black oxide steel screws
- Lumenier Neoprene landing pads
- Easy battery access ( It is recommended to use 1300mAh 3 - 4s Li-Po )
- Multiple motor mounting holes ( M3 and M2 screw mounting patterns ) fit a variety of motors
- "Bumpers" on the end of the arms protect the motor from a crash, just like those of the QAV250
- The upper plate of the chassis includes slots for SMA connector and video transmitter as well as a holder for the XT - 60 Li-Po pigtail
- The PDB powers the ESCs and FPV flight electronics with the XT - 60 Li-Po pigtail
- The PDB can be connected to a Pololu 12V or 5V step-down voltage regulator ( The Pololu board is not included )
- It supports 26mm and 32mm board cameras like the Lumenier CM â 650, and HD camera ( such as the GoPro 4, Mobius, or GoPro Session ) with an additional camera mount ( not included )
Specifications:
Wheelbase: 220mm / 8.7 inches
Size: 208 x 160 x 45mm / 8.2 x 6.3 x 1.8 inches
Net weight: 124g
In order to take full advantages of the carbon fiber chassis, you may consider choosing the following multicopter parts:
Motor: 2204 2300KV, 2205 2300KV, 2206 2300KV
ESC: 20A - 30A
Propeller: 4045 - 5045
Flight controller: NAZE32, F3
Battery: 11.4 - 14.8V 25 - 75C 1300 - 1500mAh 3 - 4S
The carbon fiber is popular among the RC hobbyists, because it excels in both light weight and sturdiness. Choose the durable material, and your beloved quadcopter will be your long-time companion!
Main Features:
- The full 3K carbon fiber airframe features a solid 2mm main plate and 4mm removable arms
- Custom aluminum hardware enables the quick replacement of arms in race
- Black oxide steel screws
- Lumenier Neoprene landing pads
- Easy battery access ( It is recommended to use 1300mAh 3 - 4s Li-Po )
- Multiple motor mounting holes ( M3 and M2 screw mounting patterns ) fit a variety of motors
- "Bumpers" on the end of the arms protect the motor from a crash, just like those of the QAV250
- The upper plate of the chassis includes slots for SMA connector and video transmitter as well as a holder for the XT - 60 Li-Po pigtail
- The PDB powers the ESCs and FPV flight electronics with the XT - 60 Li-Po pigtail
- The PDB can be connected to a Pololu 12V or 5V step-down voltage regulator ( The Pololu board is not included )
- It supports 26mm and 32mm board cameras like the Lumenier CM â 650, and HD camera ( such as the GoPro 4, Mobius, or GoPro Session ) with an additional camera mount ( not included )
Specifications:
Wheelbase: 220mm / 8.7 inches
Size: 208 x 160 x 45mm / 8.2 x 6.3 x 1.8 inches
Net weight: 124g
In order to take full advantages of the carbon fiber chassis, you may consider choosing the following multicopter parts:
Motor: 2204 2300KV, 2205 2300KV, 2206 2300KV
ESC: 20A - 30A
Propeller: 4045 - 5045
Flight controller: NAZE32, F3
Battery: 11.4 - 14.8V 25 - 75C 1300 - 1500mAh 3 - 4S
Specifications
General |
Type: Body Frame |
|---|---|
Racing Quadcopter Parameters |
Wheelbase: 220mm / 8.7 inches |
Dimension and Weight |
Product weight: 0.124 kg
Package weight: 0.230 kg Product size (L x W x H): 20.80 x 16.00 x 45.00 cm / 8.19 x 6.3 x 17.72 inches Package size (L x W x H): 17.00 x 10.00 x 4.00 cm / 6.69 x 3.94 x 1.57 inches |
Package Contents |
Package Contents: 1 x GB220 220mm Carbon Fiber Chassis ( including 1 x Upper Plate, 1 x Lower Plate, 4 x Arm, 1 x PDB, 4 x Landing Pad, 1 x Pack of Fixing Shafts, 1 x Pack of Screws, 1 x Camera Holder, 2 x Lateral Plate, 1 x Junction Plate ) |
