Main Features:
- Considerate Durable Design
All the propellers, motors, and electronic components are protected by the carbon fiber frame, which prevents them in the event of a crash since the impact distributes much more evenly.
- Amazing Agility
It is extremely maneuverable because of the "x" configuration and the perfect center of gravity.
- Ease of Maintenance
It is easy to replace the parts of the frame because it consists of modular components and soldering is not needed.
- Perfect Connectivity
The 600TVL HD aerial view can be transmitted in the real time thanks to the 5.8G 32CH FPV transmitter.
Required:
500 - 1000mAh 11.1V Battery
Transmitter
Receiver
Specifications:
Frame
Model: GB110
Wheelbase: 110mm
Material: 100% carbon fiber
Weight: 55g
DYS 1306 4000KV Motor
Size: 18 Ã 15mm
Shaft: 2mm main shaft, 5mm prop shaft
Recommended voltage: 2 - 3S ( 7.4 - 11.1V )
Weight: 13.6g ( not including connectors and hardware )
Mounting holes: M2
DYS XM20A BLHeli ESC
Input voltage: 2 - 4S LiPo
Signal frequency: 20 - 500Hz
Output PWM frequency: 18KHz
Compatibility: SimonK, BLHeli
Size: 23 x 12 x 4.5mm
Weight: 7.6g
F3 6DOF Flight Controller
Size: 35 x 35mm
Weight: 6g
Propeller
Type: 3030 three-blade
Color: red, black
Aomway 200mW FPV Transmitter
Modulation: wideband FM
Channels: 32
Video format: NTSC / PAL
Output impedance: 50 ohm
Output power: 23 - 24dBm
Operating voltage: 7 - 24V
Supply current: 190mA
Operating temperature: -10 to 85 Deg.C
Video band width: 0 - 8.0 MHz
Audio carrier frequency: 6.5MHz
Video input level: 0.8 - 1.2 Vp-p
Video input impedance: 75 ohm
Audio input level: 0.5 - 2.0 Vp-p
Audio input impedance: 10k ohm
Connector: SMA ( not RP )
Size: 26 x 23 x 8mm
Weight: 6g ( not including antenna )
Specification
General |
Type: Frame Kit |
|---|---|
Motor |
KV: 4000
No. of Cells: 2 - 3S |
Camera |
Video Resolution: 600TVL |
Dimension and Weight |
Product weight: 0.200 kg
Package weight: 0.350 kg Product size (L x W x H): 16.20 x 16.20 x 4.50 cm / 6.38 x 6.38 x 1.77 inches Package size (L x W x H): 27.00 x 23.00 x 12.00 cm / 10.63 x 9.06 x 4.72 inches |
Package Contents |
Package Contents: 1 x Drone |
