Main Features:
- Considerate Durable Design
All the propellers, motors, and electronic components are protected by the carbon fiber frame, which prevents them in the event of a crash since the impact distributes much more evenly.
- Amazing Agility
It is extremely maneuverable because of the "x" configuration and the perfect center of gravity.
- Ease of Maintenance
It is easy to replace the parts of the frame because it consists of modular components and soldering is not needed.
- Perfect Connectivity
The 600TVL HD aerial view can be transmitted in the real time thanks to the 5.8G 32CH FPV transmitter. Additionally, the RadioLink T8FB2.4GHz 8CH Transmitter enables your drone to be controlled within 1,000m.
Required:
Battery: 500 - 1000mAh 11.1V ( not included )
Specifications:
Frame
Model: GB110
Wheelbase: 110mm
Material: 100% carbon fiber
Weight: 55g
DYS 1306 4000KV Motor
Size: 18 Ã 15mm
Shaft: 2mm main shaft, 5mm prop shaft
Recommended voltage: 2 - 3S ( 7.4 - 11.1V )
Weight: 13.6g ( not including connectors and hardware )
Mounting holes: M2
DYS XM20A BLHeli ESC
Input voltage: 2 - 4S LiPo
Signal frequency: 20 - 500Hz
Output PWM frequency: 18KHz
Compatibility: SimonK, BLHeli
Size: 23 x 12 x 4.5mm
Weight: 7.6g
F3 6DOF Flight Controller
Size: 35 x 35mm
Weight: 6g
Propeller
Type: 3030 three-blade
Color: red, black
Aomway 200mW FPV Transmitter
Modulation: wideband FM
Channels: 32
Video format: NTSC / PAL
Output impedance: 50 ohm
Output power: 23 - 24dBm
Operating voltage: 7 - 24V
Supply current: 190mA
Operating temperature: -10 to 85 Deg.C
Video band width: 0 - 8.0 MHz
Audio carrier frequency: 6.5MHz
Video input level: 0.8 - 1.2 Vp-p
Video input impedance: 75 ohm
Audio input level: 0.5 - 2.0 Vp-p
Audio input impedance: 10k ohm
Connector: SMA ( not RP )
Size: 26 x 23 x 8mm
Weight: 6g ( not including antenna )
RadioLink T8FB
Size: T8FB - 173 x 102 x 206mm, R8EH - 48.5 x 21 x 11mm
Weight: 0.47kg ( including R8EH )
Frequency: 2.4GHz ISM band ( 2400 - 2483.5MHz )
Modulation mode: GFSK
Channel bandwidth: 400KHz
Band width: 1200KHz
Spread spectrum: FHSS
Adjacent channel rejection: more than 36dBm
Transmitter power: less than 100mW ( 20dBm )
Sensitivity: -104dBm
Speed rate: 38kbps
PWM output: 1.0 - 2.0ms
Section precision: 2000, 0.5us per section
Cycle: 15 ms/per frame
T8FB operating voltage: 4.8 - 18V
T8FB operating current: less than 110mA
R8EH operating voltage: 4.6 - 10V
R8EH operating current: less than 30mA
Control distance: more than 1000m in the air ( depending on the environment )
Specification
General |
Type: Frame Kit |
|---|---|
Motor |
KV: 4000
No. of Cells: 2 - 3S |
Connectivity |
Channel: 8-Channels
Remote Control: 2.4GHz Wireless Radio Control Detailed Control Distance: 1000m |
Camera |
Video Resolution: 600TVL |
Racing Quadcopter Parameters |
Wheelbase: 110mm |
Dimension and Weight |
Product weight: 0.200 kg
Package weight: 0.450 kg Product size (L x W x H): 16.20 x 16.20 x 4.50 cm / 6.38 x 6.38 x 1.77 inches Package size (L x W x H): 27.00 x 23.00 x 12.00 cm / 10.63 x 9.06 x 4.72 inches |
Package Contents |
Package Contents: 1 x Drone, 1 x RadioLink T8FB Transmitter Set |
