Garila S2405 1900KV 2400KV 2700KV Brushless Motor for FPV Racer 5Pcs Combo for RC Drone FPV Racing - 95.00 €

Garila S2405 1900KV 2400KV 2700KV Brushless Motor for FPV Racer 5Pcs Combo for RC Drone FPV Racing
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

5X Garila S2405 1900KV 2400KV 2700KV FPV Racing Brushless Motor for FPV Racer




Specification:
Brand name: Garila
Item name: S2405 1900KV 2400KV 2700KV motor

1900KV
Stator Diameter: 24.0 mm (0.945 in)
Stator Thickness: 5.0 mm(0.197 in)
No. of Stator Arms: 12
Magnet Poles: 14
Motor KV: 1900 RPM / Volt
No-Load Current (Io/12V): 1.54Amps
Motor Resistance (Rm): 44.3mΩ
Maximum Continuous Current: Amps/Max Continuous Power
Weight: 34.5Grams (1.217oz) Lead wire length(Suit 4-1 ESC)130mm
Outside Diameter: 30.24 mm (1.19 in)
Shaft Diameter(inside): 4.0 mm (0.157 in)
Prop Shaft Diameter(outside): 5.0 mm (0.197 in)
Body Length: 19.5mm (0.77 in)
Overall Shaft Length: 33.5 mm (1.32 in)
Max LiPoly Cell: 4~6s
Prop: 5~6 inch
Drive Frequency: 2.22 kHz


2400KV
Stator Diameter: 24.0 mm (0.945 in)
Stator Thickness: 5.0 mm(0.197 in)
No. of Stator Arms: 12
Magnet Poles: 14
Motor KV: 2400 RPM / Volt
No-Load Current (Io/12V): 1.54Amps
Motor Resistance (Rm): 44.3mΩ
Maximum Continuous Current: Amps/Max Continuous Power
(5-cell Li-Po): Watts Prop.: 5” 20V*43A= 860 W
(4-cell Li-Po) : Watts Prop.: 6” 14.8V*50A= 740W
Weight: 34.5Grams (1.217oz) Lead wire length(Suit 4-1 ESC)130mm
Outside Diameter: 30.24 mm (1.19 in)
Shaft Diameter(inside): 4.0 mm (0.157 in)
Prop Shaft Diameter(outside): 5.0 mm (0.197 in)
Body Length: 19.5mm (0.77 in)
Overall Shaft Length: 33.5 mm (1.32 in)
Max LiPoly Cell: 4~5s
Prop: 5~6 inch
Drive Frequency: 2.87 kHz


2700KV
Stator Diameter: 24.0 mm (0.945 in)
Stator Thickness: 5.0 mm(0.197 in)
No. of Stator Arms: 12
Magnet Poles: 14
Motor KV: 2700 RPM / Volt
No-Load Current (Io/12V): 1.69Amps
Motor Resistance (Rm): 40.51mΩ
Maximum Continuous Current: Amps/Max Continuous Power
(5-cell Li-Po): Watts Prop.: 5” 21V*59A= 1239 W
(3-cell Li-Po) : Watts Prop.: 6” 12.6V*48.4A= 609.8W
Weight: 34.5Grams (1.217oz) Lead wire length(Suit 4-1 ESC)130mm
Outside Diameter: 30.24 mm (1.19 in)
Shaft Diameter(inside): 4.0 mm (0.157 in)
Prop Shaft Diameter(outside): 5.0 mm (0.197 in)
Body Length: 19.5mm (0.77 in)
Overall Shaft Length: 33.5 mm (1.32 in)
Max LiPoly Cell: 3~5s
Prop: 5~6 inch
Drive Frequency: 3.17 kHz

Package Incldued:
5 x S2405 Motor
4 x M5 flanged lock nut
16+2 x M3*6 screws
