FuriousFPV RADIANCE DSHOT600 F3 Flight Controller Built-in BEC LC Filter And Current Sensor
Description:
With the Radiance FC, this system beautifully stacks with 4in1 ESC for perfect CG, allowing a center of the frame layout to
optimize acro flight. And considering the aircraft PDB will be utilized, weight is paired down.
optimize acro flight. And considering the aircraft PDB will be utilized, weight is paired down.
High performance and user friendly, the Radiance features cutting edge F3 chip MPU6000 processing power, built in BEC,
integrated LC filter, iLap transponder, and a current sensor input, just to name a few. With this feature packed insanity, the
Radiance shadows all other FC's, providing everything that's needed in one perfect package.
integrated LC filter, iLap transponder, and a current sensor input, just to name a few. With this feature packed insanity, the
Radiance shadows all other FC's, providing everything that's needed in one perfect package.
Item name: FuriousFPV RADIANCE DSHOT600 F3 FC
Size: 36*36mm
Mounting hole:30.5*30.5mm
Weight: about 5g
Screw: M3
Latest Generation F3 Processor Chip
High Performance, User Friendly F3 MPU6000 Chip
Integrated LC Filter for Perfect Clarity
Designed for Acro Precision via CG Perfection
Heavy Duty 1A BEC @ 5V Output and 0.8A BEC @12V Output
Included Spektrum Satellite Port
2S-5S Lipo Ready
Support DSHOT protocol
Support DSHOT protocol
Inrush Voltage Protection Input by Transient Voltage Suppressor
Gold Plated Pads for the Very Best Connectivity
New RADIANCE DSHOT Version Update:
-Remove PPM pin and add TX2 pin For the pinnacle in simplicity, performance-
-Support DSHOT protocol
-New component for better BEC protection
-New RED color
Features:
-Designed to be utilized with a stackable 4 in 1 ESC layout, the Radiance offers center of gravity perfection by placing
the lion's share of the weight in the middle of the frame.
-Utilizing the MPU6000 chip, the radiance takes advantage of high performance gyro performance that syncs at 2KHz with high
vibration resistance, allowing hard mounting options versus traditional vibration isolating methods.
-With an integrated LC filter, video clarity is perfected, offering ultra levels of video quality that keep you in the sky under the
most demanding RF conditions.
-With iLap Transponder technology, which tallies your laps during the race.
-Built-in 5V 1A and 12V 0.8A regulator (BEC), have options to choose either using 12V for high voltage VTXs/cameras or 5V BEC
for led strips or 5V VTXs/cameras.
-With an integrated current sensor monitor input, you can keep track of crucial current as you fly, allowing you to keep tabs on power
in demand - real time.
BETAFLIGHT TARGET: Betaflight_3.1.7_RADIANCE_DS.hex
https://github.com/furiousfpv/betaflight/releases
User manual: Radiance Dshot600
Package included:
1* FuriousFPV RADIANCE DSHOT600 F3 flight controller
Features:
-Designed to be utilized with a stackable 4 in 1 ESC layout, the Radiance offers center of gravity perfection by placing
the lion's share of the weight in the middle of the frame.
-Utilizing the MPU6000 chip, the radiance takes advantage of high performance gyro performance that syncs at 2KHz with high
vibration resistance, allowing hard mounting options versus traditional vibration isolating methods.
-With an integrated LC filter, video clarity is perfected, offering ultra levels of video quality that keep you in the sky under the
most demanding RF conditions.
-With iLap Transponder technology, which tallies your laps during the race.
-Built-in 5V 1A and 12V 0.8A regulator (BEC), have options to choose either using 12V for high voltage VTXs/cameras or 5V BEC
for led strips or 5V VTXs/cameras.
-With an integrated current sensor monitor input, you can keep track of crucial current as you fly, allowing you to keep tabs on power
in demand - real time.
BETAFLIGHT TARGET: Betaflight_3.1.7_RADIANCE_DS.hex
https://github.com/furiousfpv/betaflight/releases
User manual: Radiance Dshot600
Package included:
1* FuriousFPV RADIANCE DSHOT600 F3 flight controller
