The FrSky R9 Slim+ receiver is the updated version of R9 Slim, with optimized performance and 2 detachable antennas. The R9 Slim+ has all the features of the R9 Slim with the flexibility to work with more external devices by incorporating the inverted SBUS and S.Port outputs.
Specification:
Number of Channels:
Non-EU Version: 6/16CH (Telemetry)
With RSSI Output : Analog 0~3.3V
Operating Voltage Range: DC 3.5V~12.6V(3s Li-Battery)
Operating Current: 100mA@5V
Operating Range: Up to 10km or above
Firmware Upgradable
Compatibility: R9M and R9M Lite
Dimension: 32*13.5*5mm (L × W × H)
Weight: 4.3g (with antennas)
Feature:
915MHz (Non-EU Version)/ 868MHz(EU Version)
Performance optimized
2 detachable ipex connector antennas
Small and conveniently setup
Low latency and high precision
Support redundancy function
Smart Port enabled and support telemetry data transmission
Battery voltage detection
With RSSI output
With inverted SBUS and S.Port outputs
Package Included:
1 x R9 Slim+ Receiver
