Description:
Product: FPV Single Lens
Signal Input: AV(P/N)
Working Voltage: 5-8V
Resolution: QVGA 320X240
Low Power: <100mW
Support: 8-bit RGB-serial data, Hd, Vd, Valid, Clock
CCIR 601, CCIR656
Display Active Size: 4.05X3.02mm
Display Diagonal: 5mm(0.20”)
Display Pixel: 13.5um
Filling Rate: 94%
Color Depth: 4200000
Display Frame Rate: 120HZ(NTSC),100HZ(PAL)
Constrast Ratio: 80:1
Working Temp: -10â~70â
Packing Size: 15.2X11.3X9.2mm
Note:
The red line- BRIGHTNESS+
The black line- BRIGHTNESS-
The yellow line- DGND
The green line- AV +(AGND)
The blue line- AV -( VIDEO IN)
The white line- Power +(DGND)
The orange line- Power -(+5V)
Package:
1* FPV Single Lens
