Porduct Feature:
Small volume, light and easy operation, plug and play.
This item allow you to quickly and efficently connect with myopia glasses, presbyopic glasses, sunglasses lossless. Extensively suitable for various consumer groups.
Application:
Can widely replace all sores of handhold display
Monitor for aremodelling
Display of electronic magnifier
Fishing finder display
Monitor for particular position and scene shot
Operation:
1. Connect monocular displayer with outside video signal through video input wires, after the connection, turn on the video equipment and input the video signal.
2. Adjust the position of the monocular display on the glasses as you will so that to get the best viewing results(Figure)
3. In the condition of indoor or other safe environments, if wearing the displayer on glasses in short time, mount the displayer to the glasses with 4 rubber suncker of the ocular. Continuous use time should be within 1 hour, fix the video input wires outside of glasses leg with ty-wrap.
4. In the condition of outdoor or other may scratch the displayer environment, or need wearing for long time, pull down TPU rubber ring of the displayer, put the rubber ring the lens, fix the video input wires outside of glasses leg with ty-wrap.
5. The material of TPU rubber ring is an anti-aging rubber.Tension is 5.5kg, non proof, non anti cut.
6. The spare 4 TPU rubber ring can temporarily be used to strengthen the display mounting in case of trouble.
Dimensions: 15.2*11.3*9.2mm
Net Weight:<15g
Working temperature: -10 ~70â
Storage temperature: -30 ~83â
Specification:
Virtual Size: 78 inches screen (Fictitous distance 2 meters)
Resolution: RGB-432x240 (Similar to white light 640x480RGB)
Video Input: Simulation CVBS
Viewing Angle: 26°
Operating Voltage: DC3.5V-5V
Operating Current: <120mA
Power consumption: <0.6w
Package Included:
1 x Monocular Display
2 x Ocular
1 x Video Wire
1 x Manual
