1/3 Sony CCD 800TVL FPV Camera for QAV250 FPV Racing
Description:
Item Name: SONY 800TVL Camera
Sensor: 1/3" Sony 960H Exview HAD CCD II
Size: 32mm*32mm
Weight: 13g
Resolution: PAL: 1020H×596V (0.61MP) NTSC: 1020H×508V (0.52MP)
Effective Resolution: PAL: 976H×582V (0.57MP) NTSC: 976H×494V (0.48MP)
Format: PAL/NTSC
Resolution(horizontal center): 800TVL
DNR: 2DNR Support 0-15 adjustable
Lux: 0.01LUX/F1.2
SNR: ≥48dB
Video Output: 1.0Vp-p/75Ω
Automatic Gain Control: 0.25/0.50/0.75/1.00 adjustable,up to 55dB
AWB: ON/OFF
BLC: HLC/ Backlight Compensation
ASPM: eletronic exposure
Electronic Shutter: 1/50(1/60) - 1/100000 second
Gamma Correction: 0.45/1.0
Synchronization Mode: Internal Synchronization
Lens: Standard 3.6mm lens
Working Voltage: DC12V(Wide Voltage,Measured that can be work in 7.5-13V)
Workig Current: 70mA (low power consumption)
Working Temp.: -20â--60â
Humidity: 0%~ 98%
Package Included:
1 x Camera
