Description:
FS - X6B is a 6-channel two-way receiver designed for multirotors. It uses the AFHDS 2A ( Automatic Frequency Hopping Digital System ) protocol and dual omnidirectional antenna, featuring superior noise reduction techniques. Compact and easy-to-install, it offers friendly user interface. More importantly, it supports 6-channel PWM output, standard 8-channel PPM output as well as 18-channel iBUS output.
Specifications:
Channels: 6 ( PWM ), 8 ( PPM ), 18 ( iBUS )
Model type: multirotor
RF range: 2.408 - 2.475 GHz
Brand width: 500KHz
Number of bands: 135
RF power: no more than 20dBm
Sensitivity: -95dBm
2.4GHz protocol: AFHDS 2A
Modulation type: GFSK
Stick resolution: 1024
Low voltage alarm: yes
DSC port: PPM / PWM / iBUS
Antenna length: 93mm ( dual antennas )
Power input: 4.0 - 8.4V
Online update: yes ( wireless )
Range: more than 300m
Weight: 4.5g
Size: 36 x 22 x 7.5mm
iBUS port: yes
Certificate: CE0678, FCC
Compatibility: all AFHDS 2A transmitters, such as FS - i10, FS - i6, FS - i6S, FS - i6X, FS - i4, FS - i4X, FS - TM10, FS - TM8
Specification
General |
Brand: Flysky
Type: Receiver |
|---|---|
Dimension and Weight |
Package weight: 0.040 kg
Product size (L x W x H): 3.60 x 2.20 x 0.75 cm / 1.42 x 0.87 x 0.3 inches Package size (L x W x H): 5.00 x 3.00 x 2.00 cm / 1.97 x 1.18 x 0.79 inches |
Package Contents |
Package Contents: 1 x Receiver, 4 x Cable |
