Description:
Brand Name:FlySky
Item Name: FS-i6 transmitter + FS-R6B receiver
FS-i6 Specifications:
Version: Mode 2 (Left Hand Throttle)
Channels: 6 Channels
Model Type: Glider/Heli/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF Power: Less Than 20dBm
2.4ghz System: AFHDS 2A and AFHDS
Code Type: GFSK
Sensitivity: 1024
Low Voltage Warning: less than 4.2V
DSC Port: PS2;Output:PPM
Charger Port: No
ANT length: 26mm*2(dual antenna)
Transmitter Weight: 392g
Package Weight: 676g
Transmitter Size: 174x89x190mm
Package Size: 23.5x21.2x10.6cm
Power: 6V 1.5AA*4
Display Mode: Transflective STN positive type, 128*64 dot matrix VA73*39mm,white backlight.
On-line Update: Yes
Color: Black
Certificate: CE0678,FCC
Model Memories: 20
Control Range: 500m
FS-R6B Receiver Specifications:
Brand Name: Flysky
Item Name: FS-R6B Receiver
2.4ghz System: AFHDS
Item Name: FS-R6B Receiver
2.4ghz System: AFHDS
Channels: 6 Channels
Model Type: Heli/airplane
RF Power: Less than 20DBm
Modulation: GFSK
Code Type: PCM
Senditivity: 1024
Low Voltage Warning: LED
Charger Port: Yes
ANT Length: 26mm
Frequency: 2.4G
Power: 5V DC(1.5V AAA*4)
Weight: 25g
Size: 30*25*8mm
Certificate: CE,FCC,RoHS
Note:
The i6 transmitter can support both AFHDS and AFHDS 2A, the R6B receiver can only support AFHDS.
English Manual, Click Here
Package Included:
1x Flysky i6 Transmitter
1x Flysky R6B Receiver
1x Bind Plug
Note:
The i6 transmitter can support both AFHDS and AFHDS 2A, the R6B receiver can only support AFHDS.
English Manual, Click Here
Package Included:
1x Flysky i6 Transmitter
1x Flysky R6B Receiver
1x Bind Plug
