Specification:
Item Name: Flyshark X218 5 Inch 5.8G FPV Racing Drone
Model: X218
| Frame Kit |
Wheelbase: 218mm
Arm Plate Thickness: 4mm
Bottom Plate Thickness: 4mm
Side Plate Thickness: 3mm
Material: Carbon Fiber
Color: Black
|
|
Flight Controller Integrated with VTX Module |
Brand Name: Rcharlance Model: F4 PRO + V2 Item Name: F4 OSD FC AIO VTX Module
Size: 36x36mm
Mounting Hole: 30.5x30.5mm
Flight Controller:Net Weight: 12g (not including cable) Processor: STM32F405
Gyroscope: MPU6000(Reserved external gyroscope interface)
Barometer: BMP280
Firmware: Betaflight OMNIBUS F4SD
Input Voltage: 2-6S Lipo
BEC Output: 5V 3A
Fimware: betaflihgt_3.2.0_OMNIBUSF4SD
- Built-in OSD (support BF Ground Station adjust OSD)
- Adjust the PID by OSD via remote control
- Support SAMRT AUDIO, adjust the VTX by OSD (UART3)
- MicroSD card blackbox
- Support PPM, SBUS, IBUS, DSM2/ DSMX Receiver (UART1)FPV Transmitter: Channel: 40CH Power: 25/200/600/800mW ( Switchable)
Frequency: 5362-5945MHZ
Video Format: NTSC/PAL
Working Voltage: DC 7-24V Output Voltage: 5V @ 450mA Working Current: 25mW@ 240mA; 200mW@340mA; 600mW@520mA; 800mW@600mA
RemoteSoftwareprotocol: SmartAudio V2.0
Audio Bandwidth: 6.5MHZ
Video Bandwidth: 18MHZ
Range: Up to 4km omnidirectional RHCP antennas
Connector: MMCX
Supports smart audio (remote parameter adjustment) |
| 40A BLheli_32 4 in 1 ESC |
Con. Current: 40A Peak Current: 50A BEC Output: NO Firmware: BLheli_32 Mounting Hole: 30.5x30.5mm - Built-in Current Sensor - Dshot1200 up to 32kHz Support Damped Mode, Oneshot125, Oneshot42, Multishot Support Dshot150, Dshot300, Dshot600, forward and reverse - Auto timing feature |
| Rcharlance DT2306 2400KV Motor |
Brand Name: Rcharlance Model: DT2306 Item Name: 2306 2400KV Motor Lipo Battery: 2-4S
Spindle diameter: 23mm
Spindle length: 6mm
Out shaft diameter: 5mm
Motor size: Φ33.5 × 39.1mm
Thrust: 2600g (16V 5048 3-blade prop) |
| 800TVL 1/3 CCD FPV Camera |
Horizontal resolution: 800TVL
TV system: PAL / NTSC
5D-OSD button: yes
Input voltage: 12V DC
Dimensions(mm): 25X25(W*L)
Menu (OSD): English menu
White Dot Repair: Support
Image Adjustment: Support
Weight: 14.6g(with bracket)
Power Consumption: 70mA
|
| Frsky XM+ Receiver ( BNF Version Only ) |
Number of channels: up to 16CH from SBUS (1-15ch for PWM,16ch RSSI for FC)
Operating voltage range: 3.7~10V
Operating current: 30mA @5V
Operating range: full range
With RSSI output on board: analog 0~3.3V
Firmware upgradeable
Dimension: 21.5*12*3.5mm(L x W x H)
Weight: 1.6g
|
Package Included:
1x 218mm Carbon Fiber Frame Kit
1x Rcharlance F4PRO+ Flight Controller 5.8G 48CH FPV
1x 40A Blheli-32 4 In 1 ESC
1x 800TVL CCD CAMERA
4x 2306-2400KV
4x Programmable RGB LED lights
4 x purple propeller CW
4 x purple propeller CCW
1 x Antenna
1 x Battery plate
1 x Battery strap
1 x Camera bracket (Gopro)
