Description:
FVT Swallow Series aircraft ESC’s pack a wide array of adjustments and tunability into a heavy duty speed controller. Swallow Series ESC’s feature generous use of high-quality components and integrated heat-sinks to increase efficiency, lower operating temperatures and increase run times.
Specifications:
Brand Name: Favourite/FVTSeries: Swallow
Item Name: Brushless ESC
Constant Current: 45A
Burst Current (10s): 60A
Operating Voltage: 2-4S LiPo
BEC Output: 5V/3A
Dimension: 55x28x9mm
Weight: 30g
Programmable: Yes
USB Link and PC software can be used to update firmware online.
Package Included:
1x FVT Swallow Series 45A 2-4S Brushless ESC
USB Link and PC software can be used to update firmware online.
Adjustable Parameters (requires program card):
• Brake (on/off)
• Battery type
• Cut-off type
• Cut-off voltage
• Motor timing
• Start mode
• Governor mode
• Motor direction
Features:
Features:
Multiple motor timing choices, so compatible with most brushless motors in the market.
Microprocessor uses separate voltage regulator IC, with good anti-jamming capability.
Self detection and warning function: When the throttle stick is inadequate, the motor will not start and emit "Beep-beep".
Multiple protection features: over-heat protection and throttle signal loss protection,low voltage cut-off protection.
Throttle calibration funtion: Throttle range can be calibrated to be compatible with different transmitters.
Package Included:
1x FVT Swallow Series 45A 2-4S Brushless ESC
