F2 Mito210 210mm FPV Racing Drone Freestyle True X Frame Kit Carbon Fiber 4mm Arm

Description:

Item name: F2 Mito210 frame kit

Wheelbase: 210mm(5 inch)

Arm thickness: 4mm

Bottom plate thickness: 2mm

Upper plate thickness: 2mm

Side plate thickness: 1.5mm

Height of aluminum column: 30mm

Camera angle range: 0-60 °

Weight: 82g

Material: 3K carbon fiber

Color: red/black (optional)

Features:
Quick disassembly design.
4mm independent arm, fast demolition, unique design virtual bit less.
We also designed a fixed four arm of the aluminum alloy, so that the arm is not easy to shift.
True X structure, suitable for racing with Freestyle fancy flight.

The position of the motor compartment is widened and the collision is not easy to hit the motor.

Machine all use 12.9 strength YFS screws.

According to individual needs, can choose the frame assembly of battery on or under.

support HS1170, Swift, RunCam Eagle 2, Foxeer Arrow V3 HS1195, RunCam Sparrow, Swift 2 MINI, OVL and other lenses.

Recommend parts:

Flight controller: F4/F3/Naze32/CC3D

Motor: 2204/2205/2206/2305/2306/2405...brushless motor

ESC: 20-30A brushless ESC

Propeller: 4-5 inch (4XXX/50XX)

Battery: 3/4S 1300-1800mAh lipo battery

This product is an empty machine version, without any electronic equipment.

Package included:

1 x F2 Mito210 frame kit
