Working frequency: 5.8G
Working channel: 48CH
Transmitting power: 5mW/100mW/200mW/OFF(PitMode)
Working voltage: DC2.5-5.5V
Antenna: copper tube antenna
Weight: 4.2g
Volume: 18.3x13.6x17mm
Operating current (5V): 260mA (25mW) / 300mA (100mW) / 360mA (200mW)
Operating current (5V): 260mA (25mW) / 300mA (100mW) / 360mA (200mW)
Features:
3 LED lights, 1 butto
Support external OSD
Channel changes through S.BUS
700VTL camera,120 Degree FOV
Miniature and light weight design
Betaflight/Cleanflight OSD configuring parameter
Adjustable 4 modes:25mW/100mW/200mW/OFF(PitMode)
Smaller current (5V supply: 200mW current is only 360mA)
Clean powerup and channel switching without interference to others
Intensive capacitive filtering to solve ripple, interference and power stability issues
Note: 1. Make sure that there is enough space for airflow when installing the module
on the drone in case the overheating protection starts to reduce the power even to shut down at the worst.
on the drone in case the overheating protection starts to reduce the power even to shut down at the worst.
2. Please install the antenna before powering up for a longer use life
Package included:
1 x EWRF e7082VT 5.8G 48CH 25/100/200mW/PitMode FPV Camera Transmitter Support OSD/SBUS Configuring
Package included:
1 x EWRF e7082VT 5.8G 48CH 25/100/200mW/PitMode FPV Camera Transmitter Support OSD/SBUS Configuring
