Emax Nighthawk X4 170mm Carbon Fiber X Frame Kit High Speed 4mm Arm with PDB - 45.00 €

Emax Nighthawk X4 170mm Carbon Fiber X Frame Kit High Speed 4mm Arm with PDB
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Emax Nighthawk X4 170mm Carbon Fiber X Frame Kit High Speed 4mm Arm with PDB















Specification:
Brand Name: Emax
Model: Nighthawk X4
Item Name: Emax Nighthawk X4 170mm X Frame Kit
Material: Carbon Fiber
Wheelbase: 170mm
Arm Thickness: 4mm
Bottom Plate: 1.5mm
Top Plate: 1.5mm
PDB Thickness: 1.5mm
3Programmable RGB LEDs (Runs on 5V)
PDB Power Output: Filtered 12V @ 2A and 5V @ 3A Switching Regulators
Weight: 123g

Features:
- EMAX’s first pure X frames with equidistant motor placement and centered mass for the ultimate in balance and agility.

- A custom PDB with Dual Shielded Voltage Regulators, integrated XT60 battery connector, low voltage buzzer and programmable LED strip.

-The built-in PDB serves as the top half of the main structural frame, eliminating the need for another carbon piece to save precious weight.

-With all the components arranged towards the center, its center of gravity allows the X frame to turn in an instant.

-Adjustable HD Camera Mount clips on top of the included Top plate and locks into place. Using the screws to loosen or tighten the angle adjustment mechanism, the mount can swivel from 30-45 degrees to let your HD Cam capture the most angled speed runs.


Recommended Parts:(Not Included)
Propeller: 4 Inch Propeller
Flight Control: Emax Skyline32, F3 Flight Control
ESC:12A-20A ESC
Motor: Emax RS2205 2600KV Motor
Battery: 3S 1000-1500mAH ≥50C Battery

The fllowing parts are suitable for this frame:
Flight Control: EMAX Skyline32 Flight Control Board with OSD,
SP Racing F3 Flight Control
Propeller: 2 Pair DAL 4x4.5 4045 4 Inch Propeller,
DYS T4045 4 Inch Propeller
ESC: EMAX BLHeli lightning 20A ESC
Motor: Emax RS2205 2205 2600KV Racing Edition Motor
Battery: XF Power 11.1V 1500MAH 3S 60C Lipo Battery


Package Included:
1x EMAX Nighthawk X4 Frame
1x 5V/12V PDB
1x Action Camera Mount
