Specification:
Brand Name: EMAX
Item Name: 5.8G 40CH 25mW 200mW Switchable FPV Transmitter
Channel: 40CH
Power: 25mW / 200mW Switchable
Application: Original part for EMAX Babyhawk R 2 Inch / 3 Inch FPV Drone
How to change VTX CH / Power?
1.Entry / Exit menu
(1)Press 5 seconds to enter menu.
(2)Press 5 seconds again to exit menu.
2.Selection menu
After entering the menu,click the button to switch the band(R)/ Channel(C)/ power(P).
3.Entry / Exit parameters
(1)After selecting the menu, press 2 seconds to enter the parameter selection.
(2)Press 2 seconds again to exit the parameter selection and go back to the menu
option.
(3)Press 5 seconds to exit menu directly.
4.Selection parameter
When you enter the parameter, click the button to select parameters.
Package Included:
1x 5.8G 40CH 25/200mW VTX
Package Included:
1x 5.8G 40CH 25/200mW VTX
