Notice: It is DIY Version that comes unassembled.
Specification:
Brand Name: Eachine
Model: Tyro109
Version: PNP ( Without Receiver)
Weight: 311g
| Item | Specification |
| 210mm Frame Kit |
Wheel base: 210mm
Frame arm thickness: 5mm
Bottom plate thickness: 2mm
Side plate thickness: 2mm
Frame kit material: 3K carbon fiber & 6065 aluminium
|
| 2206 2400KV Brushless Motor |
KV: 2400KV Idle current (Io/10V): 1.26A
Lipo cell: 3-5S
Weight: 31g
Max continuous current: 31A
Max continuous power: 496W
Max thrust: 1050g (4S/5")
Configu-ration: 12N/14P
Motor resistance (RM): 0.0572 Ω
Stator diameter: 22mm
Stator thickness: 6mm
Motor diameter: 27.7mm
Motor body length: 19.2mm
Overall shaft length: 34.2mm
Prop adapter shaft: M5
Bolt holes spacing: 16mm
Bolt thread: M3
Propeller: 5-6 inch
|
| 4 IN 1 30A BLHeli_S ESC |
Continuous current: 30A
Peak Current: 40A(10S)
Input voltage: 2-5S
BEC: 5V 2A BEC
Main control chip: 48Mhz EFM8BB2
Firmware: BLHeli_S supports Dshot600
MOS: 5*6
|
| Customized F4 Flight Controller |
Main control chip: STM32F405
Sensor: ICM20602 6-axis
Power supply: 5V
Integrated OSD
Onboard LC filter
PID cycle rate & gyro refresh rate up to 32Khz
Supports BetaFlight / inav racing firmware
|
| Caddx Turbo Eos2 1200TVL Camera |
FOV: 160°
DNR: 2DNR
WDR: D-WDR
Lens: 2.1mm
TV System: NSTC
Latency: min 3ms
Resolution: 1200TVL
Illumination: 0.005LUX
Schutter: Rolling Schutter
Power Input: 3.3V-9V
Image Sensor: 1/3 inch COMS
Aspect Ration: 16:9 / 4:3 choosable
Net weight: 5g
Dimension: 14 * 14 * 16mm
Package weight: 41g
Package dimension: 66 * 66 * 32mm
|
| Xf5804 5.8G 40CH 0mW/25mw/200mw/600mw switchable VTX |
Output power & transmission distance: ≥0.5km@25mW, ≥1km@200mW, ≥2km@600mW
Transmitting power: 0mW/25mW/200mW/600mW
Full video format: NTSC /PAL
Input voltage & power dissipation: 7V~24V, +12V/260mA@600mW
Size: 20*30*9mm
Weight: ≤7g(except antenna)
With output power self-check function.
Nixie tube SCAN: frequency point (1-8), frequency band (A-E), power (1-3, 0=0mw, 1=25mw, 2=200mw, 3=600mw)
|
| 5040 5 Inch 4-Blade Propeller |
Material: PC
Mounting hole: 5mm
Center thickness: 8mm
Color: blue & purple
Quantity: 4 CW + 4 CCW
|
| Battery |
Not included Recommend 3-5S |
Package Included:
1 x 210mm frame kit
2 x 2206 2400KV brushless motor CW
2 x 2206 2400KV brushless motor CCW
1 x 4 IN 1 30A BLHeli_S ESC
1 x Customized F4 flight controller
1 x Caddx Turbo Eos2 1200tvl
1 x XF5804 5.8G 40CH 0mw/25mw/200mw/600mw switchable VTX
2 x Battery strap
4x 5040 four-blade propeller CW
4 x 5040 four-blade propeller CCW
