DYS Storm 2207 2300KV 2500KV 3-4S Brushless Motor for Racing Drone - 21.99 €

DYS Storm 2207 2300KV 2500KV 3-4S Brushless Motor for Racing Drone
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


DYS Storm 2207 2300KV 2500KV 3-4S Brushless Motor for Racing Drone











Test Table:

2300KV


2500KV


Specification:
Brand Name: DYS
Item Name: 2207 2300KV 2500KV 3-4S Brushless Motor
Model: Storm
KV: 2300KV 2500KV ( Optional)
Screw Thread: CW Screw Thread
Lipo Battery: 3-4S
Shaft: M5 hollow shaft
Configu Ration: NP
Stator Diameter: 22.0mm
Stator Length: 7.0mm
Motor Dimensions(Dia.*Len): Φ27.7x18.7mm
Max Continuous current(A): 29.3A (2300KV); 34.1A (2550KV)
Max Continuous Power(W): 468.8W (2300KV); 545.6W (2550KV)
Internal resistance: 0.04Ω (2300KV); 0.06Ω (2550KV)

Imported ISC bearing
0.1mm laminations
N54 magnets
Weight:37.73g


Package Included:
1x DYS 2207 Motor
1x Motor Nut
10x Screws
