Dynam Scout 980mm Wingspan EPO Trainer Beginner RC Airplane DY8924V2 SRTF Mode 2
Description:
General
Brand Name: Dynam
Item Name: Scout
Item NO.: DY8924V2
Dimension and Weight
Wingspan: 980mm
Overall Length: 767mm
Wing Area: 13.7dã¡
Wing Loading: 24.5g/dã¡
Flying Weight: 335g
Package Weight: About 3kg
Electronic Devices
Servo: 7g x 3pcs
Motor: Brushless Outrunner BM2313A-KV1850
ESC: 18A with 3A BEC
Battery: 7.4V 850mAh 15C LiPo
Transmitter: DetrumTech GAVIN-6A 2.4G 6CH TX
Receiver: DetrumTech MSR66A RX
Balance Charger: For 2-3 cells
Others
Minimum Age Recommendation: 14+
Recommended Environment: Outdoor
Specification Of Transmitter:
Brand Name: DetrumTech
Item Name: GAVIN-6A
Channel: 6-channel
Type: Mode 2 (Left hand throttle)
Type: Mode 2 (Left hand throttle)
Transmitting Frequency: 2.4GHz
Spread Spectrum: DSSS&FHSS
Power Supply: AA batteries 1.5V *4pcs
Consuming Current: less than or equal to 200mA
Output Power: 100mW
Output Pulse: 1000ms~2000ms (neutral 1500ms)
Specification Of Receiver:
Brand Name: DetrumTech
Item Name: MSR66A
Channel: 6
Dimension: 37*20*13mm
Weight: 7.0g
Frequency: 2.4GHz
Communication Distance: >1.1Km
Power Supply: 3.6V~16V
Output Signal: PWM
Features of Airplane:SRTF version,with stabilization receiver,ready to fly. Everything you need is included in the box.
Beatiful appearance,reasonable architectural design
Attractive white paint scheme and decal trim sheet
Powerful BM2313A-KV1850 brushless outrunner motor
Easy assembly,easy maintenance.
Features of GAVIN-6A Transmitter:
Applicable for airplanes.
Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple frequence-hopping spread spectrum (FHSS) technology, the R/C system has high receiving sensitivity and strong anti-interference capability, can support a stable operating for more than 1km on the ground and more than 1.6km in the air.
Adopting wireless chips, with extended power amplifier (PA) and low noise amplifier (LNA) can extremely improve the system output power and receiving sensitivity.
The transmitting efficiency is greatly improved by using all-band antenna on transmitter.
Can experience a smooth flight operation by using the 4096 section precision.
Using low power devices could reduce the transmitting power, also lead to low battery power consumption and longer battery life.
Support one button to toggle between off, V-tail mixing and elevon mixing.
Battery level LED indicators and low battery alarm function make the flight safer.
Four digital trims make your operation more accurately.
Features of MSR66A Receiver:
Features of MSR66A Receiver:
32-bit high-performance ARM core processor, 6-axis MEMS gyro chipset
The size of MSR66A is super small (37*20mm), it is more suitable for small-scale aircraft which can fly in the park.
Original airplane attitude stabilization algorithm and control algorithm. Support normal wing, fly wing, V-tail airplanes, and 3D planes.
Four flight modes: Gyro off, Normal, Aerobatic, and Auto-Recovery (Auto Balance). You can switch between different modes by the toggle switch.
Set the gain and other programmable items with matched transmitter or program card.
MSR66A adopts 2.4GHz direct sequence spread spectrum (DSSS) and multiple frequency-hopping (FHSS) technologies, having high receiving sensitivity and strong anti-interference capability.
By using diversity antenna, combined with the signal detection and switching algorithm, the receiving signal is stable and reliable.
Once the binding is made, the ID code is stored in the receiver and no further binding is necessary after restarting the receiver.
If the aircraft flies out of the remote control range and cannot receive a valid RF signal from the transmitter, SR86A’s outputs can be driven to their preset failsafe positions.
DY8924V2 English Manual,
MSR66A Reveiver Manual,
GAVIN-6A Transmitter Manual,
Package Included:
1x Dynam Scout 980mm EPO Trainer RC Airplane
1x DetrumTech GAVIN-6A Transmitter
1x DetrumTech MSR66A Receiver
