Dynam Hawksky FPV 1370mm Wingspan EPO FPV Glider RC Airplane SRTF With FPV System - 259.00 €

Seller: Banggood,

Free shipping aviable, Registered postage from 25 €

Dynam Hawksky FPV 1370mm Wingspan EPO FPV RC Airplane SRTF

Description of Airplane:
Brand Name: Dynam
Item Name: Hawksky FPV
Material: EPO
Wingspan: 1370mm(53.9in)
Length: 950mm(37.4in)
Flying Weight: 847g
Motor: BM2810A-KV1900
Servo: 9g×4
ESC: 30A ESC with 3A BEC
Battery: 3S 11.1V 2200mAh 25C Lipo battey

Specification of Video Transmission:
Working Frequency: 5.8GHz ISM
Output Power: 200mW
Channel: 48CH
Input Voltage: DC 7V~17V
Supply Current: 260mA/12V
Antenna Connector: 50Ω SMA
Antenna Gain: 2dBi
Video Input Impedance: 75Ω
Video Band Width: 8MHz
Video Format: NTSC/PAL
Working Temperature: -40~85â
Dimension(L×W×H): 32×21×9mm

Specification of Camera:
Lens: 3MP, 2.1mm
Horizontal Resolution: 800TVL
Video Standard: PAL/NTSC
Power Input: 3.5V~6V

Description of Transmitter & Receiver:
GAVIN-6A is a 2.4GHz 6-channel transmitter, applicable for airplane. Using low power devices leads to longer battery life. Support two stick modes to meet different operating habits and support one button to toggle between off, V-tail mixing and elevon mixing. Combined with optional SR86A receiver or ISTONE-A PRO flight controller for airplane, one-click rescue function can be easily used for new beginner.

RXC6 Mini Receiver is a 2.4GHz 6-channel normal receiver with mini size. By using diversity antenna, can automatically switch the signals to ensure the stability of the received signal. The RXC6 will set the output according to transmitter’s Fail Safe function when receiver cannot receive signal.

All using the DSSS&FHSS dual spread spectrum technology, will enhance the transmitter by increasing the anti-interference performance and transmission distance, even can controlled normally in city center, do not worry about the strong interference from high voltage lines, signal towers, city WiFi, etc.

Specification of Transmitter:
Version: Mode 1, Mode 2 (optional)
Channel: 6-channel
Transmitting Frequency: 2.4GHz
Spread Spectrum: DSSS&FHSS
Power Supply: AA batteries 1.5V *4pcs (not included)
Consuming Current: less than or equal to 200mA
Output Power: 100mW
Output Pulse: 1000ms~2000ms (neutral 1500ms)

Specification of Receiver:
Dimension: 20*33*12.5mm
Weight: 6.9g
Frequency: 2.4GHz
Communication Distance>1.1km
Power Supply: 3.6V~16VOutput Signal: PWM

Features of Airplane:

- Hawksky FPV is specially designed for the FPV enthusiast based on the Hawksky V2.

- Sticking with Hawksky aircraft type, Hawksky FPV is super stable and capable of maintaining flight at super slow speeds.

- When worked with ISTONE-All stabilizer or MSR66A sport receiver, the airplane can recover to the level flight automatically in any emergency, which allow novice to master flight mechanics with ease.

- It flies gentle and can glide well, which can reduce the power consumption and make you enjoy the FPV in a relaxed mood.

- The pusher configuration and the camera mounted on the nose can give you great vision.

- 5.8G 200mW video transmission makes you enjoy the scenery beyond visual range.

- Considering the transportability and usability of it, Hawksky FPV airplane uses the locking mechanism between the wings and fuselage which is easy for assembly and disassembly.

- You can launch it by hand so that they do not need to taxis for a long time before taking off.

Features of Transmitter:
- Applicable for airplanes.
- Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple frequence-hopping spread spectrum (FHSS) technology, the R/C system has high receiving sensitivity and strong anti-interference capability, can support a stable operating for more than 1km on the ground and more than 1.6km in the air.
- Adopting wireless chips, with extended power amplifier (PA) and low noise amplifier (LNA) can extremely improve the system output power and receiving sensitivity.
- The transmitting efficiency is greatly improved by using all-band antenna on transmitter.
- Can experience a smooth flight operation by using the 4096 section precision
- Using low power devices could reduce the transmitting power, also lead to low battery power consumption and longer battery life.
- Support one button to toggle between off, V-tail mixing and elevon mixing.
- Battery level LED indicators and low battery alarm function make the flight safer.
- Four digital trims make your operation more accurately.

Features of Receiver:
- Using ARM M3 processor, provides strong resolution capability.
- The size of RXC6 is super small (33*20mm), it is more suitable for small-scale aircraft which can fly in the park.
- Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple frequency-hopping spread spectrum (FHSS) technology, the receiver has high sensitivity and strong anti-interference capability, can receive signal stably for more than 1,000 meters in the air.
- By using diversity antenna, can automatically switch the signals to ensure the stability of the received signal.
- Each transmitter has an individually assigned, unique ID code. Once the binding is made, the ID code is stored in the receiver and no further binding is necessary after restarting the receiver.
- When the aircraft flies out of range, the receiver cannot receive a valid RF signal from the transmitter, and will move the servos to predefined position.

Package Included:
1x Dynam Hawksky FPV 1370mm Wingspan EPO FPV RC Airplane
1x Transmitter
1x Receiver
1x Video Transmitter
1x Camera
1x Battery
1x Charger
