Dualsky XC0610BA V2 6A 2-3S Brushless ESC With 5V/1A BEC For RC Airplane Helicopters
Description:
Brand Name: Dualsky
Item Name: XC0610BA V2
Dimension: 25x12x6mm
Weight: 5.5g
Number of Cell: NiXX 5-10S,6-12V or LiPo 2-3S,7.4-11V
Resistance: 0.04Ω
Max Cont. Current: 6A
Max Burst Current: 8A
Max Cont. Output: 63W
Max Burst Output: 82W
BEC: 5V/1A
BEC Type: Linear
Programmable: Throttle +ProgCARD+USB Link
Input Wires: 80mm,22AWG,JST
Output Wires: 40mm,22AWG,DB2
Signal Wire: 120mm JR
Features:
Features:
The new designed 2nd version software and hardware have many features.
Supports all motor types up to 210,000 rpm (2 Poles motors)
Normal, Soft or Super-Soft start up modes avaliable,for both fixed wing and helicopter setups.
DLBM on/off-Dualsky Linear Brake Mode. Brake strength can be adjusted by transmitter when switch on.
Full protection features including: Low voltage cut-off, Over heating protection,signal loss auto cut-off.
Stable linear BEC power supply,support up to 3S LiPo.
Smooth and accurate throttle control throughout the range.
Throttle digital signal sampling,compatible with the signal frequency of 14ms Normal mode and 7ms high-speed mode (HS Mode).
Throttle range can be re-calibrated,so suitable for all brands of transmitter.
Fully PC programmable when used with Dualsky USB link(NOT included).
Compatible with program card (NOT included) for easy re-programming at the field.
Package Included:
1x Dualsky XC0610BA V2 6A ESC
Package Included:
1x Dualsky XC0610BA V2 6A ESC
