Dualsky VR Pro Duo High End Linear Regulator For 100CC Gasoline RC Airplane
Description:
Brand Name: Dualsky
Item Name: VR Pro Duo High End Linear Regulator
Input voltage: DC 5.3V -8.4V, MAX10V (2S LiPo)
Output Voltage: 5V, 6V, 7.4V (Switchable, Tolerance + 3%)
Output Current: DC 0 -15A (Vin-Vout =1V)
Minimum Differential Voltage: < 0.3V
Power Effect: 0.3%
Voltage Effect: 0.3%
Output Ripple: ≤ 2mV
Size: 63mmX32mmX18mm
Weight: 62g (including duo input wires)
English Manual,
Package Included:
1x Dualsky VR Pro Duo High End Linear Regulator
Design features:
Miniaturization design, input & output port using horizontal row;
Dual battery input design, automatic switching and balancing between batteries;
4 current outputs, support 4 channel servos direct connection;
Plug and play. No need to weld the connectors;
Internal dual input voltage monitor for low voltage with memory function;
Support HV servos (7.4V), output voltage is switchable;
Includes FSS-3, the failure safety switch with status indicator, VR Pro Duo also supports FSS-4 lightweight switch;
Equipped with heat sink and external cooling fan;
Support up to 10pcs of 30kg digital servo;
Can be used on the largest 13KG model aircraft, eg.100CC Gasoline Powered Aircraft.
Electrical Features:
Linear regulator, no interference, low ripple;
The input power uses simulated diode dual redundancy power supply;
Double MosFET output, independent linear control IC, high output current capability;
Low dropout design makes fully use of the cell's capacity, especially on HV mode;
Large heat sink, good heat dissipation and high overload capacity;
Built-in MCU precisely controls FSS-3 and internal voltage;
Fail safe design, ensuring Non-stop work;
SMT process, ensureing the quality;
Input & output port all use high quality tantalum capacitors;
Dualsky Shanghai factory assembled, fully tested before dispatch.
English Manual,
Package Included:
1x Dualsky VR Pro Duo High End Linear Regulator
